Backlog — core

Forward-looking to-build items for the core / infrastructure domain (src/core/, src/platform/, build, CI, network, persistence, UI). The light-domain counterpart is backlog-light.md; items that genuinely span both are in backlog-mixed.md. Index + overview: README.md. Completed items are removed.

The audio-sync test waits on the wall clock (2026-09-06)

test/unit/core/unit_AudioService_sync.cpp drives the quiet-packet case with platform::delayMs(1) inside a 100-iteration polling loop, so the assertion that level reaches zero depends on real elapsed time and on loopback UDP delivering within that window. It passes today and has not been seen to flake, but it is the shape that produces a rare CI failure nobody can reproduce, and it spends real milliseconds in a suite that otherwise runs on a test clock.

The fix is the deterministic UDP seam plus platform::setTestNowMs, the same pattern every other timing test here uses: feed the packet, advance the clock explicitly, assert. Raised by CodeRabbit on PR #96 and deliberately not taken in that pass: it is pre-existing rather than part of that diff, and swapping a test's transport is a change that wants its own verification.

Distribution

OTA upload refuses a normal client: the body must arrive within ~50 ms (2026-09-02)

POST /api/firmware/upload answers 400 {"error":"incomplete request body"} to an ordinary curl --data-binary @firmware.bin, in 37 ms, before reading the image at all.

The streaming branch sets bodyNeeded to the whole prefix buffer and then polls for it with a 50-iteration, 1 ms budget (HttpServerModule.cpp, the read loop). A client that writes its headers and pauses before the body, which curl does, trips that timeout and is rejected. The browser path works because fetch hands the whole body to the socket at once.

Worked around by writing headers plus the first 8 KB in a single sendall from a small Python client, after which a 1.97 MB image uploaded in 6.3 s and the device rebooted correctly. So the transfer is fine; the acceptance test is what is wrong.

Worth fixing because OTA is the only route to a board whose USB port is unavailable, which is exactly when a firmware update matters most. The fix is to wait for the CONTENT-LENGTH the client declared rather than for a buffer to fill, and to time out on stall rather than on total elapsed.

Release 2.0 — distribution catches up to the source tree

1.0 ships ESP32 firmware (4 variants) + macOS arm64 + Windows x64. Still to add:

• ESP32-P4 firmware variant — esp32p4rev1-eth (Ethernet-only) shipped: in build_esp32.py's FIRMWARES, the deviceModels.json catalog (Waveshare P4-NANO), and CI builds + publishes it to the web installer + releases. esp32p4rev1-eth-wifi now ships too (2026-08-19): it boots and associates on IDF v6.1-rc1, so it is out of the experimental set in the installer and carries a normal description. Its open defect is throughput, not shipping — see § ESP32-P4 round 3, open issue 0.
• ESP32-S31 web-flash (waiting on esptool-js) — the esp32s31 firmware ships (build, catalog, CI matrix, web installer listing), and CLI flashing works (flash_esp32.py → esptool.py, which has S31 support since v5.2.0). Browser flashing does not: the web installer's esptool-js (pinned 0.5.7) has no S31 chip class. Worse than a missing entry — the S31's ROM magic (15736195) collides with the classic ESP32's; esptool.py disambiguates with secondary register detection (S31 USES_MAGIC_VALUE=False), but esptool-js has only the magic table, so it would mis-identify the RISC-V S31 as a classic Xtensa ESP32 and flash the wrong stub/params. install.js's WEB_FLASH_UNSUPPORTED_CHIPS guard catches an S31 connect-flash failure and points the user at the CLI. No upstream timeline: as of 2026-06 the esptool-js repo has zero S31 issues/PRs/commits and its last release was 2026-03 (it lags esptool.py on new chips by months). Removal trigger: when esptool-js ships S31 support with the secondary detection (not just a magic-table entry — re-check the chip-detect switch, not the version number), bump the esptool-js pin in install-orchestrator.js and drop ESP32-S31 from WEB_FLASH_UNSUPPORTED_CHIPS.
• ESP32-P4 v3.x silicon variant (backlog) — esp32p4rev1-eth is built for pre-v3 P4 (CONFIG_ESP32P4_SELECTS_REV_LESS_V3 + REV_MIN_0), because the v6.1 IDF default (v3.1) refused to boot on the bench/field v1.x P4 and rev <3.0 vs >=3.0 are "huge hardware difference" (one binary can't cover both). DONE (2026-08-19): esp32p4rev3-eth and esp32p4rev3-eth-wifi ship (REV_MIN_300, which covers v3.0-v3.99), reusing the rev1 board fragment so the partition table and EMAC config stay in one place. Still open: neither has ever been booted — both bench boards are v1.3 engineering samples, so the rev3 images are flagged experimental in the installer and need a v3 board to verify. Espressif does not recommend v0.x/v1.x for new designs, so a board bought today is v3.x and needs these.
• Teensy 4.1 — toolchain-file build, .hex for Teensy Loader.
• Raspberry Pi — ARM64, cross-built or native.
• macOS code-signing (Developer ID) — the release .dmg is now ad-hoc signed, which turns Gatekeeper's outright refusal into the "unidentified developer" prompt a user can accept via right-click Open. A paid Developer ID certificate plus notarization would drop that prompt too.
• Windows code-signing — drops the SmartScreen warning on first run of projectMM.exe. Same shape as macOS signing; needs an EV / OV code-signing certificate (Microsoft Trusted Signing is the cheapest current option). Until then, the README notes the SmartScreen prompt.
• Live RMII Ethernet reconfigure — runtime PHY/pin config shipped (ethType + pin controls in NetworkModule, per-board defaults in deviceModels.json, platform::setEthConfig/ethInit dispatch). W5500 (SPI) on S3 applies live — ethStop() tears down the SPI bus and ethInit() re-runs on the next loop1s() with no reboot. RMII (classic/P4 internal EMAC) still saves config and asks for a restart to apply, because the EMAC bring-up is fiddlier to hot-cycle cleanly. Make RMII live too: a hot esp_eth_stop + EMAC/netif teardown + re-init on config change, matching the W5500 path, so every interface honours the no-reboot principle.
• GCC below 16 needs four warnings demoted, and nothing exercises those versions - -Wnull-dereference, -Wrestrict, -Wstringop-overflow and -Wformat-truncation fire on provably correct code from GCC 12 through 15 (five of the twelve inside libstdc++ and glibc headers, unreachable from our source), so CMakeLists demotes them to non-fatal there and keeps them fatal on 16+. That unblocks CI and from-source builds on Debian and Raspberry Pi OS alike, but it is a suppression, not an understanding: nobody routinely compiles with 12-15, so a REAL instance of one of these on those versions is now a warning nobody reads. Revisit when the runner's default GCC reaches 16, at which point the whole block can be deleted.
• Installer UX polish — clear "Pre-release (beta)" warning on RC/latest picks, yank-by-asset-tag instead of yank-by-release-deletion.
• Offer projectMM/MoonLight as a library — a downstream sketch where another firmware/app consumes the light pipeline (or a subset) as an embeddable dependency rather than running the whole binary. library.json is already a PlatformIO library manifest, so the seed exists. When this is designed, give it a small public identity surface: one runtime constant the consumer reads (a kProjectName, likely a ProjectInfo bundle of name + version + url) that the network wire-strings (ArtNet/E1.31 source-name + CID), the UI banner, and any "About" string all derive from — the one place a consumer queries "what am I embedding." This is the genuine home for the name-centralisation that the rename (rename-to-moonlight.md § Phase 1.3) deliberately didn't do: the rename is a one-time sweep (a constant would just split it), but a library consumer references the identity ongoing and widely, which is the test a constant must pass. Build it then, against the real library API, not speculatively now.
• HTTP: a request whose headers or body arrive a few ms late is dropped, intermittently (2026-08-20). handleConnection runs SYNCHRONOUSLY inside tick20ms, so its waits are kept short to protect the render loop: a freshly accepted connection gets ~5 ms for its request headers (HttpServerModule.cpp, the empties > 5 bail) and ~50 ms for a body (empties > 50). A client that misses either budget gets no response at all (the header case closes the socket: "Remote end closed connection without response", seen client-side at 28 ms) or a 400 {"error":"incomplete request body"}.

Observed: the MoonLive live scenarios fail roughly 1 run in 3 on the S3, always as a failed POST /api/file that cascades (module not found for every step depending on that script). A 40-write burst failed 4/40. Not reproduced on the classic (3/3 clean), so it may be S3-specific or simply load/timing-dependent.

NOT render load — that theory is disproved. Disabling the heavy driver took the tick from 2889 us to 472 us (fps 346 → 2118) and made it WORSE: 14/40 failures instead of 4/40. So a faster tick means more accept batches per second and more chances to hit the window, which points at the budget itself rather than at contention.

Why it matters: any client on a busy or distant network can lose a write with no useful error, and the UI's own file saves ride the same route. The fix is not simply a longer wait — that would stall the render loop, which is what the budgets exist to prevent. It wants the connection handling moved off the render tick, or a state machine that parks a partial request and resumes it next tick instead of dropping it.

• Desktop backend: a control-arena write is not seen by a second run() of an already-compiled program (2026-08-20). The live-edit path is "move a slider, the next frame reads the new arena byte, no recompile". On the host JIT the first render is correct, the write lands (the arena reads back 232,3 = 1000 at the control's own offset), and a second run() of the same compiled program still renders the OLD value.

Ruled out — do not re-investigate these: - Not LoadCtrl16 missing: it is implemented, lowers to a.load16, and load16 exists in all three assemblers including platform/desktop/moonlive_asm_host.cpp (ldrh, immediate scaled). - Not uint16-specific: a uint8_t member behaves identically. - Not defineControls() or the control sink: a class with an unrelated second function fails the same way, and one with no members at all (a literal in tick) does too. - Not the arena address or offset: controlSlot(dc[0].offset) is the byte the write reaches.

A large part of the original symptom was a TEST BUG, not an engine bug. run() without an entry name starts at the BLOCK START — the first function compiled — which in a class with defineControls() is defineControls, not tick. So the script rendered nothing and looked like a broken control read. Naming kEntryTick makes the initial render correct in every variant tried (with/without defineControls, with an unrelated second function, tick first or second, uint8 and uint16). Only the re-read after a slot write is still wrong.

Reproduce (in unit_moonlive_fill.cpp, which has kCtrlTable/kSys to hand): compile class T { int big = 5; defineControls() { addControl("big", big, 0, 1000); } tick() { setRGB(0, big, 0, 0); } }, run(..., kEntryTick) → 5, write the slot to 7, run again → still 5.

Impact: desktop only, nothing ships broken. A wide control is hardware-verified on both ISAs (S3 Xtensa and S31 RISC-V drive ember's cycle to 2000 and back). What is missing is DESKTOP coverage of the live-edit loop — the path users touch most — so no host test can pin it and the next regression there would surface only on a board. Add the runtime assertion together with the fix, not before: asserting the current behavior would encode the bug.

• ESP32-P4 panics with Cache error every few minutes, pre-existing (2026-08-19): the bench P4 (Waveshare P4-NANO, esp32p4rev1-eth) reboots roughly every four minutes while IDLE, with Guru Meditation Error: Core 0 panic'ed (Cache error), sometimes followed by an Illegal instruction and a CHIP_LP_WDT_RESET on the way down.

What the device reports about its own restarts: bootReason alternates between PANIC and the watchdog. The serial shows why: the Cache error panic sometimes completes its dump and reboots cleanly (PANIC), and sometimes the panic HANDLER itself then dies with an Illegal instruction before it finishes, leaving the low-power watchdog to reset the chip (rst:0x10 CHIP_LP_WDT_RESET, W boot.esp32p4: CPU has been reset by WDT). So a WDT boot reason here is a SYMPTOM of the same fault, not a second one: nothing is hanging a task. Worth checking bootReason over several restarts rather than one, because either value can appear.

Not caused by MoonLive, and not a regression. Established by two independent checks: the board runs the DEFAULT module tree (GridLayout + NoiseEffect, no MoonLive module at all, so none of that code executes), and a firmware built from a clean main crashes identically. The filesystem is healthy throughout: LittleFS mounts, /.config lists, and writes succeed.

What is known about the fault site: MEPC resolves to pxPortGetCoprocArea (freertos/.../portable/riscv/port.c) reached from rtos_int_enter (portasm.S), which is FreeRTOS's RISC-V coprocessor-context save on INTERRUPT ENTRY. That is a symptom of something faulting inside an ISR context rather than a bug in the kernel itself, and the P4 is the only RISC-V target with a coprocessor, which is why no other board shows it. The prior art at Plan-20260718 is a DIFFERENT cause with the same panic name (an ISR reading PSRAM while a flash write disabled the cache, fixed with a spi_flash_cache_enabled() defer guard) and is worth re-reading first: the same shape on another ISR would present exactly like this.

Next step is a decoded backtrace from the full panic dump rather than the register line, then bisecting which ISR is live (audio, the LED driver, ethernet) by disabling each. Two hypotheses were tested and falsified during the session that found it, so start from evidence.

A SEPARATE P4 boot loop, also found that session, WAS a real regression and is fixed: the MoonLive engine had grown to 1440 bytes held by value in every scripted module, and registerType's T probe constructs each module on the main task's stack at boot. Re-indexing its seeded-member table by member rather than by arena byte took it to 784 bytes and the board boots clean.

• ESP32-P4 DHCP hostname not shown by the router (recheck later) — the device sets its DHCP hostname (option 12 = deviceName, default MM-XXXX) in the ETHERNET_EVENT_CONNECTED handler, verified working on two boards: the S3 over WiFi (router shows MM-70BC) and the Olimex over RMII Ethernet (MM-BD3C) — the same ethEventHandler code path the P4 uses. Yet the bench P4 (Waveshare P4-NANO, RMII) still shows as blank/"Unknown" in the GL.iNet client list, while serial confirms set_hostname succeeds with no error. Two unconfirmed suspects, neither our logic: (1) the router holds a sticky lease for the P4's MAC and won't relearn the hostname until it fully expires (the per-client "forget" isn't exposed in this GL.iNet UI, and a plain reboot didn't clear it); (2) a P4-specific IDF netif quirk serializing option 12 differently on the newer P4 Ethernet path. Since the shared code path is proven on two other boards, this is not treated as a code bug. Recheck after the P4's lease naturally expires, or on a different router, before spending more on it.

DevicesModule — interop plugins + the command half (discovery shipped)

DevicesModule discovers via passive UDP presence (UDP 65506) feeding a DevicePlugin seam (shipped: projectMM + WLED plugins). mDNS is advertise-only so projectMM appears in the native WLED apps + Home Assistant; the WLED-app interop (list + live color + brightness control) is shipped too. What remains is growth on the seam, each piece additive (one plugin file, no core change):

• More discovery plugins — ESPHome, Tasmota, Hue (hub-shaped: a bridge whose Zigbee bulbs are children behind it, with link-button auth). Each is a new DevicePlugin declaring its discoveryPort() + classifying the datagram (or, for a system that only does mDNS, a re-introduced advertise-side browse scoped to foreign services only — never the ones we advertise). Hue is the canonical "more than a flat device" case the seam is shaped for. (Note: Hue control already ships as an output driver, see HueDriver — bulbs as effect pixels; the driver also lists its bridge in DevicesModule with the color-light count. Two complementary follow-ups remain: (a) auto-fill the driver's bridge IP from discovery so the user doesn't type it (the mDNS-browse plugin above); (b) pair once, not per driver — pairing + the app key currently live on each HueDriver, so two drivers on one bridge pair twice. The clean end-state moves the bridge identity (IP + key + Pair button + light list) into DevicesModule and makes HueDriver a pure output that reads the paired bridge by IP — do this together with the discovery plugin, since both hinge on DevicesModule owning the bridge.)
• The command half — DevicePlugin::command() (+ per-plugin capability/auth), so projectMM can control a discovered foreign device, not just list it: set WLED brightness via its JSON API, a Hue resource via the bridge's authenticated CLIP API, a Tasmota via cmnd. Built when a control consumer exists; the discovery seam is already shaped to accept it (incl. hub plugins). This is the multi-ecosystem selling point — one UI controlling WLED + ESPHome + Hue. Commands split by need (the rule, not "all REST"): must-arrive config over REST; latency-critical sync over UDP (~0.5–1 ms vs REST's 10–50 ms — REST would visibly de-sync).
• Live peer state — a discovered peer's brightness / on-off shown in our list, refreshed by polling its REST /json after discovery gives the IP (discovery = UDP/mDNS, state = REST). The read-side complement to the command half.
• Non-IP transports (board-gated, far future) — Tasmota-MQTT / zigbee2mqtt need an MQTT client; direct Zigbee/Thread (S31/C6/H2 802.15.4 radio) makes projectMM the hub itself, driving bulbs over the mesh with no gateway — the standout differentiator, the biggest lift. Same plugin philosophy, a transport addition + board gate.

Full design + the reasoned transport split: Plan-20260629 — UDP device discovery + mDNS advertise-only (shipped).

MoonBase follow-ups

MoonBase v1 (architecture.md § MoonBase) ships exactly one action: install firmware (upload + URL). The name is deliberately broader than "recovery", these are the candidate next actions, each solving something only a separate boot image can solve. The budget rule from the partition table applies to all of them: the 896 KB slot has ~150 KB headroom, sized for one new component, so each action must earn its bytes (a few KB of code is fine; a new IDF component is the expensive kind).

• Factory reset: erase the filesystem (and optionally NVS) from MoonBase's page: recovers a device whose config crashes the app on boot, without a USB cable.
• Boot with config disabled: one-shot flag the app reads at startup to skip loading /.config: diagnose "is it my config or the firmware?" without erasing anything.
• WiFi re-provisioning: edit the stored credentials from MoonBase's page (today it only reads them; the AP fallback plus the app's provisioning already covers most of this).
• Publish SHA-256 sums with release assets: the Defender false-positive guidance can only say "re-download over HTTPS" today; a checksums file per release lets a user verify a quarantined installer before restoring it. One sha256sum step in the release staging.
• Streamed HTTP responses drain across ticks: serveFileContents/serveHlsFile block the render tick for the whole transfer (a slow player fetching a ~1 MB HLS segment every second can hold it for hundreds of ms), and fsReadAt reopens the file per 1 KB chunk. The named fix is the writeSome/drain pattern preview already uses, plus a larger chunk.
• Re-entrant network bring-up: NetworkModule::setup() (netif create, driver install, the eth→WiFi→AP cascade) runs once at boot and crashes if re-run live, so it opts out of the live config apply (appliesConfigLive() = false) and a restored NetworkModule.json waits for the next boot. The real fix is bring-up that reconciles instead of re-creates; until then the restore dialog offers the restart.
• Config backup / restore, tiers 2+3: tier 1 (browser-side bundle over the file API, with the rename map and restore report) ships in the File Manager. Remaining: tier 2, a single-archive device endpoint (one request instead of a walk); tier 3, restore hosted on MoonBase's page, the migration answer for future partition-table moves.
• Restore clones a device's IDENTITY along with its config (found answering #76, 2026-09-04). Backup bundles every file including hidden .config, and restore writes them all back unfiltered, so restoring one device's bundle onto another copies four things that must differ per device:

field	why it must differ
deviceName	the single network identity: mDNS hostname, SoftAP SSID and DHCP hostname all derive from it (SystemModule.h). Twelve clones all answer to <name>.local, resolution goes non-deterministic, MoonDeck's device list collapses to one row
WiFi password	travels in the bundle (the UI button warns), so a shared or attached backup leaks it
a static IP	if set, every clone claims one address
universeStart and the Art-Net/DDP window	exactly what must differ per device in the light-pole case #76 describes: cloned, every pole shows the same thing

This turns "clone this pole to the other eleven" from the feature the issue wants into a trap. The fix is small and is a prerequisite for the recipe idea rather than a separate job: restore treats identity as per-device, either skipping those fields or prompting once with the target's current values prefilled. Worth deciding whether the bundle should carry the secrets at all, or keep an identity section the restoring device is expected to supply. - A backup is a file bundle, not a recipe (#76 step 2): nothing binds it to a deviceModel, so restoring a Dig-Quad bundle onto an S3 writes pin maps that do not fit the board. The 28 profiles in deviceModels.json are the missing half. - Firmware downgrade guard: MoonBase installs whatever image it is given; a version display (read from the incoming image's app descriptor) before flashing would make an accidental downgrade visible. - Hardware diagnostics: chip/flash/PSRAM identification and a minimal pin tester, for triaging a board that misbehaves under the full app. - Ethernet: shipped for classic RMII (2026-08-26). MoonBase reads the eth wiring from the same config file as the credentials (ethType gates it) and runs ONE interface at a time in the app's own preference order (eth, else WiFi, else AP), so the browser keeps the address the app had. Still open here: the P4's IP101/managed-component PHY and the S3's SPI W5500, which matter only if MoonBase ever goes beyond the 4 MB classics. - Static IP for MoonBase: MoonBase always uses DHCP; a venue network without a DHCP server (fixed-address rigs exist) would reach the app (static addressing) but not MoonBase. Read the addressing block from the same config scrape when a venue actually asks for it (the app itself applies static addressing to eth already). - MoonBase as the only update mechanism, all boards (PO, 2026-08-26): would delete the app's whole in-place OTA path (a real subtraction) and grow every app slot, with the stronger power-fail story everywhere. Three deciding factors first: MoonBase Ethernet beyond classic RMII (the P4 has no WiFi of its own and uses a different PHY; the S3 uses SPI W5500), a migration that does not lose config (backup/restore above), and accepting ~45 s of visible downtime per update where dual-OTA installs in the background. Trigger: MoonBase proven in the field on the 4 MB boards.

Provisioning and live-reconfig gaps (bench, 2026-08-26)

Both surfaced while bringing up MoonBase Ethernet on the migrated Olimex; neither is MoonBase's.

• A migrated device is not fully provisioned until the deviceModel catalog push is re-applied. After the MoonBase table migration the board ran for days with deviceModel empty and ethType 0: Improv/AP provisioning restores WiFi credentials only, and nothing tells the user the catalog half (eth wiring, per-board settings) is missing. Candidates: MoonDeck re-pushes the catalog on discovering a device whose deviceModel is empty, or the UI badges the state.
• ethType does not apply live. Setting it to 1 over the API (cable in, pins valid) left Ethernet down; the same config brought it up at the next boot. Every setting applies live is a core principle (architecture.md, Live reconfiguration), so the eth init path is missing from the control's apply/build-state sweep.

ESP32 performance and memory

Size estimates for unbuilt features (reference)

Estimates, not measurements, so they live here rather than in performance.md which carries measured numbers only. (The 4 MB flash-budget investigation these once fed is resolved: MoonBase's single-app-slot layout grew the classic app slot to 2496 KB, see architecture.md § MoonBase.)

Feature	Est.	Rationale
Mozilla cert bundle trimmed	−40 KB	CONFIG_MBEDTLS_CERTIFICATE_BUNDLE_DEFAULT_CMN keeps common roots only. _NONE saves ~50 KB but breaks TLS.
Static IPv6	+20 KB	lwIP IPv6 component (off by default). Only if a deployment needs it.
WebSocket TLS (wss://)	~0 KB	Reuses linked mbedTLS; certificate handling adds <5 KB.

E1.31 multicast receive (IGMP join)

NetworkReceiveEffect accepts E1.31 via unicast only — the same scope MoonLight ships. Multicast senders address the per-universe group 239.255.{universe_hi}.{universe_lo}, which a receiver must join via IGMP. The platform half of this now exists: UdpSocket::joinMulticast() shipped with the WLED audio-sync work (2026-08-29) and is used in anger there, on both desktop and ESP32. What is left for E1.31 is the join-per-accepted-universe bookkeeping, not the socket support. Add when a multicast-only sender actually shows up on a bench; until then the spec documents "point sACN senders at the device's IP".

The SEND half is the more interesting one, and it's the honest scale answer. sACN puts the universe number in the group address, so with IGMP snooping the switch filters per-universe in hardware — each node's NIC sees only the universes it joined. That is broadcast's send-once efficiency plus unicast's selectivity, and it's the one addressing mode that beats per-node unicast when many nodes want overlapping universes. NetworkSendDriver already knows its universe range, so the group address is a pure function of universe_start — a small increment, not a redesign. The catch that keeps it off the default path: without IGMP snooping the switch floods multicast exactly like broadcast (and on WiFi it goes out at the lowest basic rate to every station), so it degrades straight back into the starvation regime — and firmware cannot detect whether the switch snoops. So: unicast stays the portable default; multicast is the opt-in optimization for a network the user controls. Do the receive join and the send group together when it lands.

A scripted module's DIMENSION chip still comes from its type, not its script

writeModuleJson emits an instance's tags() (HttpServerModule.cpp), so a MoonLive module shows the emoji its loaded script declares. Its DIMENSION does not follow the same path: /api/types carries dim per TYPE, captured at boot from a probe with no script loaded, and the module state carries no dim at all. So a script declaring int dimensions() { return 3; } renders as 🟦 on the card while behaving as D3 through Layer::extrude: the behavior is right and the chip lies.

The fix is not a line in the serializer. MoonModule deliberately has no dimensions(): ModuleFactory::registerType detects one with if constexpr (requires ...) on the CONCRETE type precisely so the light-domain Dim enum stays out of core (ModuleFactory.h). Core holds a MoonModule* when it writes state, so emitting a per-instance dim means giving MoonModule a virtual that returns a byte, which puts a light-domain concept on the domain-neutral base for the sake of a chip.

Options, cheapest first: a uint8_t dimByte() on MoonModule defaulting to 0 (the enum stays in the light domain, only the number crosses, mirroring what the probe already does); or leave it and accept that a scripted module's dimension chip reflects its type. Worth doing when someone is annoyed by the wrong chip, not before.

British spellings and em-dashes predate the prose gate (319 files)

check_prose.py reports on ADDED lines only, so the American-spelling rule has been enforced from the day it landed forward, and everything written before it was never swept. 118 files still carry colour, centre, behaviour, recognise, initialise and friends, in comments and in a few identifiers.

Em-dashes are the same story and the larger half: 10,326 of them across 319 files under docs/, against the same rule and missed for the same reason. They are worse than the spellings to sweep mechanically, because the right replacement depends on the sentence (a colon where it explains, a comma for an aside, a full stop between two clauses), so a blind substitution produces prose nobody proofread. Count them per file and do the biggest offenders by hand.

The gate keeps it from growing, so this is a one-time sweep rather than a leak. It is deliberately NOT folded into a feature branch: a whole-repo rename touches more files than any review can read, and mixing it with real changes is how a review gets declined for size. Do it as its own commit, mechanically, with the gate run over the whole tree afterwards rather than over a diff.

Identifiers first and separately: a rename changes an API, where a comment does not. centre() in the shipped crosshair.mle was one and is already fixed, since a shipped teaching script is the highest-value case.

Now caught going forward for scripts too: .mle/.mll/.mlm joined the checker's SUFFIXES (they were unchecked, which is how colour reached ten shipped scripts), so the library cannot drift again.

Multicast discovery has no fallback when the group never arrives

DevicesModule announces presence on the multicast group and every device always joins it, so peers find each other whatever each has set wledCompatible to. The docstring states the worst case as "without IGMP snooping a switch floods multicast exactly like broadcast", i.e. it degrades to the thing it was avoiding. Field reports from other projects say the real worst case is stronger: multicast sometimes does not arrive at all, most often when the path bridges physical media (a WiFi client talking to a wired one), where consumer access points and switches handle group membership least well. Bursty delivery is reported too, packets arriving in clumps rather than at the send cadence.

That failure is silent here: peers simply never appear, and the card shows an empty list that looks exactly like a healthy single-device setup.

A periodic broadcast probe is the obvious fix and it is the wrong one. The trigger would be "no peer seen for N seconds", which is the PERMANENT state of every device that has no company, and most installs are a single device. Every one of them would broadcast forever, which is the chatter multicast was chosen to avoid, and worst on exactly the WiFi networks already struggling. A device cannot tell "the group is broken" from "I am alone" by listening: both are silence.

So the fallback needs a trigger that is not silence.

The shape that works: try broadcast because it is cheap, rather than waiting for silence to mean something. Announce on multicast, listen on BOTH, and let evidence decide. What is detectable is not "I heard nothing" but an ASYMMETRY: a peer heard over broadcast that never arrived over multicast proves the group is broken, where silence proves nothing. A device that sees that adds the broadcast copy to its own announcements and keeps it.

That needs a bootstrap, because two devices both waiting for evidence never produce any: each is quiet on broadcast, so neither gives the other the packet that would settle it. Announce on both for a bounded window after boot, then settle to multicast alone unless broadcast proved necessary. The chatter is one-time and bounded rather than permanent, which is what makes it affordable on the WiFi networks this exists for.

The control that follows is a mode rather than a compatibility flag: multicast (quiet, today's default), multicast + broadcast (what wledCompatible = true does now, and what WLED apps need), and auto (the rule above). Unicast is deliberately absent: discovery is one-to-many, and there is no address to unicast to before anything has been discovered. Document broadcast as the WLED-compatible mode rather than naming the flag after WLED.

It stays on DevicesModule rather than moving up to NetworkModule. Three places in the codebase send to a group, and only one of them is ours to choose: discovery uses projectMM's own 239.255.x.x, audio sync uses WLED's 239.0.0.1, and sACN send uses the universe-derived 239.255.{hi}.{lo} that E1.31 mandates. A network-level "prefer broadcast" switch could not move the latter two without breaking the protocols they speak, so a control there would imply an authority it does not have.

Can a device self-test by hearing its own multicast? Mostly no, and the reason is worth writing down. IP_MULTICAST_LOOP is never set anywhere in the platform layer, so it sits at the stack default, which is ON for both lwIP and BSD sockets. A device therefore hears its own multicast delivered internally, before the packet ever reaches the wire, so the test passes on a network where multicast is entirely broken. Turning loopback off makes hearing yourself meaningful, but then the test demands that the switch or AP reflect group traffic back to the sending port, which plenty deliberately do not do, so healthy networks would fail it.

What the self-test IS good for is the negative case: with loopback on, NOT hearing your own multicast means the local join or socket is broken, which is a real and actionable fault. It diagnoses the device, not the network. The network half still needs a peer, because "did my packet cross this switch" cannot be answered with nothing on the other side.

Unverified: the lwIP loopback default above is read from the socket semantics and our own code, not measured on a board. Confirm on an ESP32 before building on it.

Land the diagnosis whatever else happens. Reporting "joined the group, no peers seen" on the card costs almost nothing and turns a silent failure into a legible state, and it is useful even if the auto mode is never built.

ESP32 UDP receive is bounded by PACKET COUNT, not bytes

Reported from other projects working the same ground: the ESP32 family's incoming UDP limit behaves as a mailbox of packets rather than a memory budget, with a hard numerical ceiling, and the P4 is no better. The observed shape is perfect reception up to that count and then progressively worse loss as universes climb, rather than a clean cliff. Raising it is tunable but bounded, since the raw packet buffers are full-frame sized whatever the payload.

Two consequences worth having in mind:

• Pixels-per-packet is the lever, not bandwidth. Art-Net is DMX512 on the wire, so it is capped at 512 values per packet whatever the frame size; DDP fills close to a whole MTU. For the same pixel count DDP therefore needs far fewer packets, which is the resource that runs out first. This matches our own measurement that ArtNet is where the WiFi limit bites.
• A P4-specific escape exists. Have the packet handler DMA the payload to PSRAM and release the hardware buffer immediately, then parse from another task, so the mailbox drains at memory speed rather than at parse speed. That is real work and speculative, but it is the shape of a fix rather than a tuning knob.

Unverified on our own bench: this is other people's measurement, recorded so the next receive-path investigation starts from it rather than rediscovering it. Confirm before acting on it.

WiFi ArtNet performance (pending investigation)

128×128 WiFi ArtNet measurements exist (see performance.md "ArtNet over WiFi" and "Build-variant WiFi comparison"). Remaining matrix:

• WiFi STA 64×64 (4K LEDs, 24 universes)
• WiFi STA 32×32 (1K LEDs, 6 universes)

This determines the practical LED limit for WiFi-only boards. Until the sdkconfig.defaults TX-buffer fix lands (identified in the build-variant table), prefer wired Ethernet for any ArtNet workload on classic ESP32 — the default esp32 build carries both stacks, so Ethernet is available even when the original measurements were taken on the old esp32-eth-wifi variant.

Network round-trip test — drop/reorder measurement (deferred)

moondeck/scenario/run_network_roundtrip.py measures desktop→device→desktop latency and jitter per protocol (ArtNet/E1.31/DDP) by timing how long a sent color takes to appear in the device's preview stream. It deliberately does not measure per-frame drops or reorder, because the path can't track individual frames cleanly: NetworkSendDriver re-clocks at its own fps (decoupled from receive) and NetworkReceiveEffect holds-last-frame, so frames don't pass through 1:1 — a sequence number embedded in frame N may be re-sent 0, 1, or several times downstream. The min/median/max spread the test already reports is the jitter signal (it surfaced multi-second outliers on the classic ESP32). To measure true drop/reorder, the firmware would need a sequence-faithful echo path (e.g. a NetworkReceiveEffect echo mode that re-emits each received frame 1:1 back to the sender, bypassing the fps re-clock), then the desktop could match sent↔received sequence numbers. The test's docstring lists this under "extend later" alongside per-frame sequence matching and the device→device chain.

Async ArtNet send — decouple the wire from the render tick (PSRAM-only)

The ArtNet send is synchronous: NetworkSendDriver::loop() blasts ~97 universes (a 48 KB frame at 128×128) inline, and the per-universe send() blocks on lwIP TX backpressure — the netif/EMAC (or WiFi) drivers throttle to wire throughput. Measured on hardware: ~35 ms over Ethernet, ~90 ms over WiFi, charged straight to the render tick, so ArtNet alone caps the Olimex at ~15 FPS and the S3 (WiFi) at ~7 FPS at 128×128. This is a transport throughput limit, not something a non-blocking socket can shed — verified that neither O_NONBLOCK nor MSG_DONTWAIT makes lwIP return early for UDP (the block is below the socket API; both flags drop zero packets and cost the same ~35 ms). The earlier "non-blocking recovered it to ~2 ms" reading was a transient external condition (the receiver/switch draining the burst freely in one window), unreproducible under steady load with the exact firmware.

The real fix is a dedicated send task: loop() snapshots the corrected frame into a handoff buffer and signals the task; the send task drains it to the wire at its own pace while the render task continues. The tick stops paying the ~35–90 ms — render runs at its own rate (~30 FPS on the Olimex), ArtNet streams independently at whatever the link sustains.

Gate this on platform::hasPsram. It does not fit non-PSRAM boards at the grid sizes where it would help — the math is hard: - The handoff buffer must hold one full frame: 48 KB at 128×128 (16384 × 3), plus a ~4 KB task stack. - The Olimex (no-PSRAM) at 128×128 runs at ~46 KB free heap, ~18 KB largest contiguous block (measured). The 48 KB buffer exceeds both the total free heap and (by far) the largest block — it can't allocate at all, the same fragmentation cliff the paged MappingLUT just had to work around. - A double-buffer (so the task reads frame N while render writes N+1) doubles it to ~96 KB — even more out of reach. - At 64×64 the frame is only 12 KB and might fit, but at 64×64 the synchronous send is already fast enough that ArtNet isn't the bottleneck — so the task buys nothing where it's affordable on no-PSRAM.

So the PSRAM gate isn't conservative; it's a hard requirement. PSRAM boards (S3/S2, Olimex-with-PSRAM variants) have megabytes for the handoff buffer via heap_caps_malloc(..., MALLOC_CAP_SPIRAM); non-PSRAM boards keep the synchronous send and the documented "use Ethernet / smaller grid for high FPS at large grids" guidance (NetworkSendDriver.md).

Acceptance criteria: if constexpr (platform::hasPsram) (or a runtime hasPsram() check) selects the async path; the buffer lives in PSRAM; the send task pins to the core opposite the render task (the same pattern as the shipped render↔encode split's worker). Non-PSRAM keeps loop()'s inline send unchanged. The single handoff buffer needs an explicit ownership contract, exactly like the shipped render↔encode split's outputBuffer_: the render path may write frame N+1 only after the send task signals it has finished reading frame N (a binary semaphore/notification is the handoff), so the two never touch the buffer at once. When the sender still owns the buffer at the next render tick, the render path drops (or coalesces onto) that frame rather than overwriting a live read — a dropped frame is acceptable, a torn one is not. That single-buffer contract is the minimal shape; a second buffer (double-buffering) or a ring of frames is only warranted if measurement shows the drop rate hurts, or a second consumer appears.

esp32-eth slow Ethernet bring-up vs esp32-eth-wifi (investigation)

On Olimex ESP32-Gateway flashed with esp32-eth, Ethernet sometimes takes a minute or more to acquire a DHCP lease at boot. The same hardware flashed with esp32-eth-wifi brings Ethernet up in seconds. The B1 Idle-recovery fix in src/core/NetworkModule.h masks the symptom (status correctly transitions to "Eth: " once the lease arrives), but the underlying slow bring-up is a real performance regression on the eth-only build.

What we know: - build/esp32-esp32-eth/sdkconfig and build/esp32-esp32-eth-wifi/sdkconfig are byte-identical (3,617 lines each, cmp -s confirms). So lwIP buffer pools, DHCP timeouts, and Ethernet driver settings are the same. - Same hardware (Olimex ESP32-Gateway Rev G), same RMII pin/clock config (EMAC_CLK_OUT on GPIO17), same ethInit() code in src/platform/esp32/platform_esp32.cpp. - The only difference at link time: esp32-eth passes EXCLUDE_COMPONENTS=esp_wifi;wpa_supplicant;esp_coex to ESP-IDF (see moondeck/build/build_esp32.py:31). - esp_coex (WiFi/Bluetooth coexistence) was an early hypothesis: even though Ethernet doesn't share the radio, esp_coex's init might warm a shared clock path that helps Ethernet auto-negotiation, and the eth-only build excludes it. Disproven — see below.

Firmware is ruled out (the evidence is contradictory across reboots with the same build, which by itself proves build-independence). Over one session, on the same Olimex + cable: - esp32-eth-wifi (keeps esp_coex) → flapped: Ethernet link up → link down repeating, never reached DHCP. - esp32-eth (excludes it) → on one flash came up immediately and worked; on a later flash flapped the same way.

So the same eth-only build both works and flaps at different times, and the eth-wifi build flaps too. The instability does not track the firmware build — it's intermittent. That kills the esp_coex theory and any WiFi-interference theory. It also confirms our code isn't the cause: mm_net: Ethernet link up/down is logged straight from the ESP-IDF ETHERNET_EVENT_CONNECTED/DISCONNECTED events (platform_esp32.cpp:238-243) — the PHY hardware reports the drops; NetworkModule only reacts, never stops/restarts the link. Memory is ruled out (boot heap 286 KB, steady 133 KB free / 110 KB block — abundant).

Signature = physical layer. When flapping, the link holds for ~2 s, drops, comes back ~10 s later — a repeating cycle, not random. That fingerprints the PHY auto-negotiating, holding briefly, then losing sync: marginal PHY power, clock, cable, or connector, not firmware.

Correlates with board reset. The flapping tends to start right after a flash/soft-reset (this session: a reset preceded each flapping window; a clean power-up tended to link cleanly). Fits the documented slow/flaky PHY re-link on the Olimex after a reset — on some resets the PHY settles, on others it cycles for a long time before (or instead of) holding.

What we still don't know (all physical tests — no code change is warranted): - Does a clean power-cycle (vs soft reset) reliably link? (Tests the reset-relink correlation.) - Does barrel-jack / stronger 5V power stop it? (Tests PHY brown-out under USB-only supply, a known Olimex-Gateway weakness.) - Does swapping cable / switch port stop it? (Rules out cable/connector.)

Bottom line: intermittent, build-independent, reset-correlated → a hardware/PHY issue, not a firmware bug. The earlier "slow DHCP at boot" is likely the same root cause (the PHY cycling many times before one window holds long enough to complete DHCP). Pick this up with the physical tests above before touching any code.

MoonDeck doc-asset endpoint hardening (backlog)

moondeck/moondeck.py::_serve_doc_asset accepts any ROOT-relative path and serves the file. Path traversal is blocked (asset_path.relative_to(ROOT.resolve())), but inside the repo any file is served — including local-only artefacts like moondeck/build/wifi_credentials.json if present. MoonDeck binds to all interfaces by design (the existing comment in main() explicitly enables LAN reach), so anyone on the LAN can hit the endpoint.

Two improvements when this matters: - Subdirectory whitelist — only serve under docs/ (and image asset paths the markdown renderer needs). Reject moondeck/build/wifi_credentials.json etc. with 403. - Extension whitelist — only image / CSS / JS mime types via a small allowlist. - Optional bind-to-localhost flag — --bind 127.0.0.1 for users who don't want LAN reachability. Default stays "" (all interfaces) since the LAN-reach is the documented design.

Not blocking — MoonDeck is a developer tool, not a production server. Pick this up when MoonDeck is in scope for hardening.

A tagged release does not reach the web installer until the next main deploy (bug)

deploy-pages in .github/workflows/release.yml is gated if: github.ref == 'refs/heads/main', because the github-pages environment's protection rule only allows main. The installer's release list is staged into the Pages site at deploy time (install.js self-hosts the last 5 stable + 5 prerelease releases; the release-asset URLs redirect to a host that sends no CORS header, so the browser cannot read them from the Pages origin). Together those mean pushing a vX.Y.Z tag publishes the release but never updates the installer — the new version reaches the picker only when something later pushes to main.

Hit on v4.0.0 (2026-08-24): the release published at 16:15:59, a main deploy ran at 16:16 and enumerated releases before it existed, and the installer offered v3.0.0 as newest for hours. Re-running the workflow with the tag fixed it, and that manual re-run is the current workaround.

Note the device's own OTA picker is unaffected — it reads api.github.com live (app.js RELEASES_API), which is why a device could offer v4.0.0 while the installer could not. Two independent paths to the same release list.

restage-pages-for-tag in the same workflow already covers this: on a v* tag it re-invokes the workflow on main with tag=<the tag>, so deploy-pages runs under the allowed ref and the manifests land in releases/<tag>/. The open item is narrower than the symptom suggested — whether the dispatched run can still lose the race, since it is a second run whose release enumeration happens later, and whether relaxing the github-pages environment's branch policy (needs repo-admin) would remove the indirection entirely.

CI: pin GitHub Actions to commit SHAs (supply-chain hardening)

.github/workflows/release.yml references all 9 action types by mutable @vN tag (actions/checkout@v4, astral-sh/setup-uv@v3, softprops/action-gh-release@v2, espressif/esp-idf-ci-action@v1, …). A mutable tag can be force-moved to malicious code by a compromised publisher; pinning each uses: to a full commit SHA (with a # vN trailing comment) removes that vector. Done already (cheaper half): persist-credentials: false on every checkout that doesn't push, so the GITHUB_TOKEN isn't left in .git/config for later steps to read (the release job keeps it — it force-pushes the latest tag). Not done (this item): SHA-pinning, because it carries an ongoing cost — pinned SHAs go stale and miss security patches, so it only pays for itself alongside Dependabot (or a Renovate config) to auto-bump them. Pick this up as a deliberate "CI hardening + Dependabot" pass, not piecemeal. Low risk today: every action pinned is a first-party actions/* or a well-known publisher (astral, espressif, softprops), not an obscure third-party action.

Static IP on WiFi STA — wire the existing fields to the network (backlog)

NetworkModule exposes addressing (DHCP / Static) plus ip / gateway / subnet / dns fields, and they persist — but they are not applied to the WiFi STA interface. wifiStaInit(ssid, password) takes only credentials; the STA always runs DHCP (there is no esp_netif_dhcpc_stop + esp_netif_set_ip_info on staNetif_ — that pattern exists only for the AP). So selecting Static and entering an IP currently does nothing: the device keeps its DHCP lease. The fields are display-only scaffolding ahead of the functionality.

Implementing it needs to answer three UX/safety questions (these are the spec):

• When is it applied? NOT per-keystroke — editing the fields must only update the stored values, never reconfigure the live interface mid-entry (a valid ip with a still-zero gateway would otherwise be applied and break routing). Apply on an explicit commit — safest is on next connect / reboot, not a live switch, because changing the STA IP drops the very connection the browser UI is talking to.
• Validation before apply. Require all of ip/gateway/subnet present and self-consistent; reject 0.0.0.0 gateway/ip. If invalid, stay on DHCP rather than half-apply.
• Warn before a live change. If applied live (not reboot-deferred), the UI must confirm ("about to change this device's IP to X — you'll need to reconnect at the new address") and surface the new URL, since the current socket dies the instant the IP changes.

Platform work: extend wifiStaInit (or add wifiStaSetStatic) to take optional ip/gateway/subnet/dns and call esp_netif_dhcpc_stop + esp_netif_set_ip_info on staNetif_ when addressing is Static and the config validates. Needs careful hardware testing — a wrong static config locks the device off-network (recovery is the AP-fallback path or a flash erase). Until landed, consider hiding the Static option so it doesn't read as functional.

Memory ceiling on non-PSRAM ESP32 with eth-wifi (backlog)

On esp32-eth-wifi, default 128×128 grid, free heap at boot is ~28 KB — not enough for esp_wifi_init (needs ~16 KB RX buffers) after the light pipeline allocates ~210 KB. The device stays running but WiFi init fails silently.

Fix options in increasing scope: - Cap the default grid — drop to 64×64 on esp32-eth-wifi (Layer ~32 KB + LUT ~16 KB = 48 KB, comfortably under). Simplest. - PSRAM for Layer buffer + LUT — ESP32-Gateway has 4 MB PSRAM unused on non-S3 builds. Moving the 49 KB pixel buffer + 64 KB LUT out of DRAM frees ~110 KB for radios. Cost: ~25% FPS hit (PSRAM bandwidth ~12 MB/s vs DRAM ~80 MB/s); needs measurement. See lessons.md "Adaptive memory allocation design" for the allocation rules. - Lazy WiFi init — skip esp_wifi_init when ssid_ is empty and no AP-fallback is pending. Helps only when credentials exist but the network is unreachable — niche.

Boot-time buffer degradation on non-PSRAM at 128×128 (investigation)

On the Olimex (no-PSRAM) at 128×128 with a modifier, the Layer sometimes comes up degraded at boot — status "buffer reduced — not enough memory", with a visibly wrong render (the reduced render buffer overflows what the LUT/extrude expects). Toggling any layout control (forcing a fresh onBuildState) fixes it — the rebuild allocates the full buffer and the display is correct. So this is a boot-time allocation race, not a code bug: the same rebuild path that fails at boot succeeds moments later.

Measured: the full pipeline needs two ~49 KB contiguous buffers (Layer render buffer + Drivers output buffer, both 128×128×3), plus the LUT. At boot the largest contiguous block is only ~14–20 KB while the network stack / mDNS / HTTP-server buffers are still settling into the heap — so the Layer can't claim a contiguous 49 KB and degrades (halves its dimensions). A rebuild after the heap settles wins the contiguous block and allocates full. The device is at the fragmentation edge either way (~42 KB free / ~14 KB largest block at 128×128 with the full pipeline up).

The annoyance is purely that the device boots degraded and needs a poke to recover — it should come up working. Fix options in increasing scope: - Allocation order — claim the big Layer/Drivers buffers before the network/mDNS/HTTP buffers fragment DRAM (i.e. wire the light pipeline's onBuildState ahead of network bring-up in main.cpp). Cheapest if the ordering is safe. - Boot retry — if onBuildState degrades, schedule one more buildState() after boot settles (a one-shot, e.g. after the first loop1s or once the network reports up). Self-healing without reordering init. - Cap the default grid on no-PSRAM to a size whose two buffers fit the post-boot largest block (same lever as the eth-wifi memory ceiling above). - PSRAM for the buffers on PSRAM-equipped variants — sidesteps DRAM fragmentation entirely (related: the Async ArtNet and Memory ceiling PSRAM notes).

Related: this is the render/output-buffer face of the same non-PSRAM fragmentation cliff the paged MappingLUT already addressed for the LUT. The buffers themselves still allocate as single contiguous blocks.

Architecture

Filesystem-change notification (live preset refresh) — undesigned

ControlModule rebuilds its preset list by rescanning /.config/presets, and that rescan runs at startup and after every save, rename, delete and reorder. So a preset file uploaded or deleted through the File Manager appears only once the module next rescans (a reboot, or any preset action on the surface), not the instant the file lands. Documented as the actual behaviour in control.md.

The fix is a core-neutral filesystem-change notification: FileManagerModule (or the platform::fs* write paths) signals "this path changed", and a module with a folder it cares about re-reads. Deliberately not built yet — it is a new core seam serving one caller today, which is the shape architecture.md § Core primitives, not one-offs warns about. Build trigger: a second consumer appears (a scripted-effect folder for MoonLive is the likely one, since live scripts uploaded as files have exactly the same staleness), or the manual-refresh step proves annoying in real use.

Whatever the design, it stays domain-neutral (a path + a change kind, no preset/light vocabulary in core) and off the hot path — the notification marks a flag, the rescan happens on the owning module's next tick, never inside the writer. (CodeRabbit flagged the staleness; deferred here rather than growing the seam for one caller.)

WiFi runtime disable — open design question (undesigned)

Today the eth-only build profile compiles WiFi out (MM_NO_WIFI). Turning WiFi off at runtime instead is undesigned: whether the gate should key off detected hardware presence, an explicit control, or a deviceModel-catalog field isn't decided. The eth-only build covers the need until a concrete case forces the choice. (Moved from architecture.md § What we leave undesigned; it's a deferred design decision, not a settled 🚧 one.)

Consolidate the two module-by-name tree-walkers (backlog)

HttpServerModule::findModuleByName (findInTree recursion) and Scheduler::firstByName (firstInTree) are two implementations of the same "find the first module in tree-walk order with this name" operation. The duplication predates the setControl-to-Scheduler extraction, but that extraction made Scheduler::firstByName public and added Scheduler::instance(), so HttpServer no longer needs its own copy: its ~9 remaining call sites (identify, addModule, removeModule, clearChildren, the WLED/system shims) can call scheduler_->firstByName() and the private findModuleByName/findInTree pair deletes. Purely a No duplication cleanup — no behaviour change — worth doing so the walk order/semantics live in exactly one place. (Reviewer note, IrService/setControl branch.)

Pin-uniqueness check across modules (prevents conflicts; replaces a singleton hack)

Problem it solves. Two modules must not drive the same physical GPIO. Today nothing stops it: add two RmtLedDrivers with pins="18", or two AudioServices with the same wsPin/sdPin/sckPin, and they fight over the pin — at best garbage output, at worst (for I2S) endless i2s_new_channel driver-error spam every tick. This surfaced when a repeated catalog inject stacked duplicate AudioModules and the device spammed I2S failures (a clean install is fine; the duplicates were the artifact).

Why pin-uniqueness, not a per-type singleton. The first instinct was "make AudioService single-instance" — but that's a crude proxy. The real invariant is pin non-overlap: a board legitimately can have two LED drivers on different GPIOs (multi-output rigs do exactly this), or even two mics on distinct pin sets. "One mic" isn't fundamentally true; "no two modules on the same pin" is. So check pin conflicts, which both prevents the breakage and allows legitimate multi-instance setups. (A per-type singleInstance flag was prototyped and rejected in favour of this.)

The clean mechanism — reuse ControlType::Pin. Pins are already their own control type (the addPin work). So the check is domain-neutral and needs no per-module declaration: enumerate every Pin-typed control's value across the whole tree; a value of -1 is "unused" (ignored); any other value appearing on two controls is a conflict. Handle the list case: RmtLedDriver.pins is a comma list ("18,19,20"), so the enumerator expands list-of-pins controls too.

Where it runs. Two sites, because a pin can be introduced at add or edit: - POST /api/modules (add): if the new module's catalog/default pins collide, reject. - POST /api/control (pin write): if setting a Pin control to a value already used elsewhere, reject (or soft-flag — see below).

Open decision (UX). Conflict on add → reject with a clear message ("GPIO 18 already used by RmtLed"). Conflict on a live pin edit → reject is safest but blocks mid-reassignment (you can't swap two drivers' pins without a free intermediate); a soft-flag (accept, set a status warning) is friendlier for live editing. Leaning: reject on add, soft-flag on live edit. Product-owner call.

Hardware-limit tail (not covered by the pin check). Pin-uniqueness rejects the common case but not the controller-count limit: the S3 has 2 I2S controllers regardless of pins, so a 3rd mic on distinct pins passes the pin check yet fails i2s_new_channel at runtime. That tail is already handled — the platform I2S init returns false on failure (no panic, module stays inited_=false); verified live (4 pinned AudioModules → error spam, no crash). So scope = pin-uniqueness check + the existing graceful-degrade; don't try to make the pin check also model controller counts.

Related: the shipped "disabling releases resources" work (see docs/history/plans/) — a disabled module freeing its pins is what lets the same GPIO be reassigned live without a conflict-reject.

PinsModule — strict reject-on-add mode (the one remaining increment)

PinsModule is shipped: the read-only ownership map, reserved/strap severity grading, the conflict soft-flag (a GPIO claimed by two controls shows both owners, flagged red, never rejected), live-state dir/level/drive, and the disable-frees-pins cascade all landed — see pins-analysis-top-down.md for the shipped design record. The soft-flag choice obviated the reassignment broker (a live pin swap already works: set A→B's pin, then B→A's, the transient conflict clears).

The one still-open item is an optional strict reject-on-add mode for the installer/catalog path: a "clean tree" that refuses a module add whose pins collide, rather than accepting it soft-flagged. This is add-path validation (a different feature than the live soft-flag reassignment), wanted only if a stricter installer UX is desired. Spec + /plan if picked; the soft-flag default stays for live editing.

Runtime board presets (multi-commit, partially landed)

The firmware-vs-board separation is now in place across the codebase (see architecture.md § Firmware vs deviceModel vs board). build_esp32.py --firmware <variant> picks the compiled binary; MoonDeck deduces the physical board where the firmware uniquely identifies hardware (esp32-eth* ⇒ olimex-esp32-gateway-rev-g) and lets the user pick from a short hardcoded list otherwise. Firmware variants stay separate — esp32-eth saves ~670 KB flash + ~30 KB DRAM vs the default esp32 (WiFi+Ethernet, measured); merging would erase that win.

What still needs separation: the eth variants hardcode Olimex Gateway RMII pins in src/platform/esp32/platform_esp32.cpp::ethInit(), so they only work on that one PCB. As we add boards with different pins (LOLIN D32 tested 2026-06-02, QuinLED variants planned), runtime pin configuration becomes the next step.

Pin config moves to runtime (next, separate commit): - Drop hardcoded GPIO_NUM_17 from ethInit(). NetworkModule reads Network.eth_rmii_clock_gpio (new control) and similar pin values, defaulting to current Olimex hardcodes so behaviour is unchanged. - Same for any other hardware-pin literal in the firmware.

Board preset catalog + upload (later, when the runtime config has real consumers): - Add structured per-board files (location TBD — not docs/ since they're config not docs; boards/ at repo root is the strong candidate, matches the PlatformIO convention contributors will recognise). - Each file declares chip, flash, PSRAM, Ethernet PHY + pins, default module config. - New /api/board-preset endpoint accepts the JSON; device persists to LittleFS; bootstrap applies pins + defaults on next boot. - MoonDeck "Set board" picker reads the catalog to populate the dropdown. - Pin reassignment requires reboot (ESP-IDF can't hot-reconfigure EMAC pins after esp_eth_driver_install); document the constraint. - A first attempt at this catalog landed and was rolled back during the firmware-vs-board separation work — the catalog only earns its keep once the device reads it, otherwise it's a docs-shaped file in the wrong place.

Prior art — MoonLight's per-board pin database (ModuleIO.h). MoonLight (our own project) already models exactly this for ~25 boards across ESP32-D0 / S3 / P4: a pins[] array of {GPIO, usage, index} plus board-level maxPower, ethernetType, ethPhyAddr, ethClkMode. Don't copy the file or paste its tables here — read it when building the catalog and write our own. Its usage enum enumerates the hardware functionalities a projectMM board preset could drive once the device-side consumers exist (each needs its own module/control before the corresponding deviceModels.json / catalog field earns its keep — none exist today beyond System.deviceModel + Network.txPowerSetting):

• LED output pins — per-strip data GPIOs (1–16 outputs/board); the first real consumer (a Driver pin control) unblocks multi-output boards (QuinLED Dig-Quad/Octa, SE16, LightCrafter). This consumer now exists (the pins control on every LED driver; e.g. QuinLED Dig-Quad ships "pins": "16,3,1,4" in deviceModels.json), so the field earns its keep — but only up to 8 lanes today (kMaxLanes = 8 / kMaxPins = 8). The parallel drivers are moving to 16 lanes (choose 1..16); when they do, this becomes a real gap with two halves:
• Per-model usable-GPIO map (the data). Identify which up to 16 GPIOs each device model actually exposes for LED output — not the chip's full pin count, but the pins broken out to a usable header/connector AND safe to drive (exclude strapping, flash/PSRAM, input-only, and pins already owned by eth-RMII / I²C / the onboard LED). The codebase knows the chip ceiling (MM_MAX_GPIO from CONFIG_SOC_GPIO_PIN_COUNT, Control.h:13) and the live ownership/reserved grading (PinsModule), but NOT the per-board exposed-and-safe set — that is board knowledge (schematic/pinout per model). The authoritative source is the annotated pinout image per model under docs/assets/deviceModels/ (e.g. esp32-s3-n16r8-dev.png) (and MoonLight's ModuleIO.h pins[] as prior art — read it, write our own against deviceModels.json). Worked example — ESP32-S3-N16R8 dev board (from esp32-s3-n16r8-dev.png): the 16 safe LED-output GPIOs are 4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,21, derived by excluding — octal flash+PSRAM (the R8/N16 part reserves 26–37, the SPIIO4-7/SPIDQS/SPICLK pins), USB (19,20), UART0 console (43,44), the onboard RGB LED (38), and the strapping pins (0,3,45,46). That leaves exactly 16 clean I/O — enough for the full 16-lane target. Do the same read per model.
• Encode as per-model defaults + coverage (the catalog). The 16 usable lane GPIOs become the model's default pins string, so a fresh flash of e.g. "Serg UniShield V5" comes up with the right lane pins pre-filled, not blank/generic. Coverage today is uneven: of 25 models, 7 carry no LED-pin config (Olimex Gateway, LOLIN D32, Generic ESP32 Dev, ESP32-S3 N16R8 Dev, LightCrafter 16, SE 16 V1, and any bare dev board) — those default to nothing and force the user to guess. Fill every model's LED-capable pin default, and document the per-model map (the annotated-pin images the § below already reserves are the natural home). The per-board usable set is wider than the exposed header: a pin the board commits to a peripheral it doesn't mount is fair game (the Olimex Gateway leaves 6 clean LED pins only if you count the unmounted micro-SD pins 4/13/14 — see gpio-usage § Usable LED-output GPIOs and the bench note in memory), so the per-model map must record which non-exposed/repurposable pins are safe on this board, not just the header breakout. Scope: 16 pins max — do not over-generalize past the peripheral lane ceilings (measured lane ceilings: Parlio 65535 bytes/lane single-shot (897 RGB lights at 8 lanes, ~448 at 16), LCD 8 or 16 lanes on S3 (the widening shipped), RMT up to 8 TX channels). Note the i80 gotcha: an LcdLedDriver model should pick clockPin/dcPin clear of its data lanes — an overlap is a warning, not a blocker (the driver still runs; that one lane just carries the clock/DC waveform, which is fine for an unused parked lane but garbles an active strand), so a catalog default that overlaps an active lane would ship a subtly-broken board.
• Ethernet PHY config — LAN8720/RMII (MDC/MDIO/CLK/power-pin/PHY-addr/clock-mode) vs W5500/SPI (MISO/MOSI/SCK/CS/IRQ); the consumer is the runtime Network.eth_* controls listed above, replacing the hardcoded Olimex pins.
• Power budget — maxPower (Watts) per board, for a future current-limit / brightness-cap control.
• Audio / I2S — SD/WS/SCK/MCLK pins, the input side of audio-reactive effects (Pi-5 sensor note is the desktop counterpart).
• Buttons & inputs — push/toggle/lights-on, PIR, digital-input; needs an input-event concept the firmware doesn't have yet.
• Relays & power control — relay / lights-on / high-low pins.
• Infrared — IR receive pin (remote control).
• RS485 / DMX — TX/RX/DE pins (wired DMX-512 output beyond the current Art-Net path). The driver that consumes this is the RS-485 / DMX-512 wired output item in the light backlog.
• Sensing — voltage / current / battery / temperature ADC pins.
• Onboard LED / key, exposed / reserved pins — board-housekeeping and conflict-avoidance metadata.

Sequencing rule (unchanged): each functionality lands a device-side control first, then its preset field; the catalog grows one earned consumer at a time, never as a speculative pin dump.

Module variant + PSRAM within the classic-ESP32 family. getChipDescription() and MoonLight's ModuleIO.h both report only the core family ("ESP32"), not the module (WROOM / WROVER / PICO) — so neither distinguishes whether a classic-ESP32 board has PSRAM. This matters for projectMM (whose large-LED story leans on PSRAM) in a way it doesn't for MoonLight: e.g. the QuinLED Dig-Next-2 is built on an ESP32-PICO with 2 MB PSRAM, but projectMM's esp32 build has no CONFIG_SPIRAM (see the #ifdef CONFIG_SPIRAM gate in platform_esp32.cpp::psramAlloc), so it flashes and runs as a no-PSRAM device and hits the non-PSRAM fragmentation ceiling at large grids that the 2 MB would otherwise relieve. A PSRAM-enabled classic-ESP32 firmware variant (e.g. esp32-psram) would unlock it; deviceModels.json could then carry a psram hint per board to steer the picker — but only once that variant exists (no consumer today). deviceModels.json currently maps every classic board to the WiFi-only esp32 variant, which is correct-but-unoptimised for PSRAM-bearing PICO boards.

Per-layout coordinate offset for independent placement (backlog)

Layouts stitches multiple child layouts into one physical light space, but only their indices are stitched (offset sequentially in placeLights) — their coordinates are not translated. Two layouts therefore overlap in the same coordinate box: two 64×64 grids both occupy x,y ∈ 0..63, so the Layer's dense bounding-box buffer is 64×64 (4096 voxels) even though the container reports 8192 lights, and the second layout's lights land on the first's positions. scenario_Layouts_mutation documents this (its steps assert pipeline liveness, not buffer-size arithmetic).

When picked up: add offsetX/Y/Z (lengthType) controls to LayoutBase; Layouts::placeLights translates each child's emitted coords by its offset so layouts occupy disjoint regions of the physical extent (a 64-wide grid at offsetX=64 sits beside another at offsetX=0 → a 128×64 combined extent). Layer::onBuildState already derives physical dims from the max emitted coordinate, so it would pick up the wider extent automatically. Until then, "multiple layouts" means "multiple layouts sharing a coordinate box", which is only useful when they genuinely overlap (e.g. a sphere inscribed in a grid).

Improv as a child of NetworkModule (deferred — needs scheduler work first)

Architecturally the right shape; attempted in plan-21, reverted. Blocker: Scheduler::tick() only walks top-level modules for loop20ms/loop1s — children silently miss those callbacks. See lessons.md "Trying to add a child module to NetworkModule".

Minimum-scope fix before the move: 1. MoonModule::loop20ms/loop1s propagate to children (or Scheduler walks them) — pick whichever costs less at runtime. 2. Audit every existing override of setup/loop1s/loop20ms/onBuildControls/teardown in NetworkModule, SystemModule, FilesystemModule, HttpServerModule to confirm base-chaining. 3. Then the actual move is a one-line networkModule->addChild(improvModule) swap. Estimate ~2 h total.

Platform API: std::span migration (backlog)

Several platform.h APIs still use (buf, len) pairs where std::span would catch length/pointer mismatches at compile time. Concrete sites: http_fetch_to_ota, improvProvisioningInit, and friends. ~2 h including ripple updates to callers. Do alongside the next platform-API expansion (Windows socket port or POST /api/firmware streaming).

Improv-as-REST follow-ups

Device-model injection over Improv shipped as "Improv = REST over serial" (the APPLY_OP vendor RPC pushes the whole deviceModels.json entry over serial during install; the device runs the same apply-core the HTTP REST API does, on WiFi and eth-only firmware). That subsumed the earlier multi-step "board injection + Improv as a general data injector" plan — the general injector is APPLY_OP. What remains:

Open follow-up: closed-loop APPLY_OP pacing (read-back ack + retry). The installer paces APPLY_OP frames open-loop (sendApplyOpFrame waits a fixed ~120 ms between ops) rather than reading the device's ack back, because a Web Serial duplex read while the writer lock is held is awkward. The delay covers the worst-case single-buffer consume window with headroom, and each op is idempotent (a lost op re-applies cleanly on a re-flash), so this is robust today. The closed-loop upgrade — read the RPC response, retry once on error 0x82 (buffer busy) — removes the fixed delay (faster install) and makes op-loss impossible rather than improbable. Worth doing if a real install is ever observed dropping an op, or when the config push grows large enough that the cumulative fixed delay is noticeable. Touches only install-orchestrator.js.

Open follow-up: shared JS helpers across device-UI and mooninstaller. safeLocalGet / safeLocalSet (3-line hostile-storage guards) are duplicated in src/ui/install-picker.js (device firmware, embedded as a C string via embed_ui.cmake) and mooninstaller/devices.js (web installer page, served from Pages). The two live in different build contexts so the shared extract isn't trivial — it'd need a new src/ui/safe-storage.js plus updates to: embed_ui.cmake (embed the new file), ui_embedded.h generator (new C array), HTTP server file routing (new path served), release.yml workflow staging, preview_installer.py staging. Five files for one 3-line helper is too much pre-merge. Worth doing when the next shared helper arrives — relativeTime and formatBytes are candidates. Two helpers earn the build-glue cost; one doesn't.

Open follow-up: P4 Improv scan on a cold WiFi link (bench check). improvHandleScan in src/platform/esp32/platform_esp32_improv.cpp calls esp_wifi_scan_start, which needs the WiFi driver started. On native ESP32/S3 the driver is up by the time a user provisions; on the P4 the radio lives on the C6 and comes up only after the esp_hosted prelude in ensureWifiInit() (triggered by wifiApInit / wifiStaInit). A scan requested on a P4 that has not initialised WiFi returns an error cleanly rather than scanning a cold link, so nothing crashes. The check: bench-verify whether a P4 provisioned from cold needs the link brought up first, and if so route the scan through the public wifiAp/wifiSta path.

Live scripting — author effects/layouts/modifiers/drivers/sensor logic on-device (multi-commit, design phase)

Run user-authored scripts on a running device — a scripted effect, layout, modifier, driver, or core sensor rule, pushed as text and live on the next tick with no reflash/reboot — the leap WLED took with ARTI-FX and the heart of the PixelBlaze product. A scripted module is a MoonModule (controls, loop(), role, generic UI). The engine lives in core (domain-neutral: also "transform sensor data") and serves the light domain specifically. Targets in order: ESP32 classic + S3 first, then P4/other ESP32, then Teensy, then desktop. Must be blazingly fast (runs in the render hot path at 16K+ lights × 50 FPS), memory-smart (IRAM/PSRAM via platform::alloc, compile-once), and synced (Scheduler tick, tick-atomic hot-swap, live reconfig).

The bottom-up landscape survey is done — livescripts-analysis-bottom-up.md: deep-reads the ESPLiveScript fork (a from-scratch C-like JIT that emits native Xtensa machine code — blazingly fast but Xtensa-only, so it covers classic+S3 and not P4/Teensy/desktop), surveys the field (PixelBlaze bytecode VM + web editor, WLED ARTI-FX AST-walking interpreter, embedded VMs / WASM / lightweight multi-ISA JITs), and extracts the load-bearing decisions (execution strategy, the IR seam ESPLiveScript lacks, the MoonModule binding, the per-pixel contract, memory placement, sync, sandboxing). Its thesis to validate: a portable bytecode-VM baseline that runs on every target on day one + an optional native back-end for the hot ISAs behind a shared IR. Next: the top-down redesign — the prompt that generates livescripts-analysis-top-down.md is at the bottom of the bottom-up doc; it produces the reference architecture + staged spike plan. Implementation is multi-commit, spike-ordered, after the top-down lands. Credits: friend-repos/hpwit-ESPLiveScript.md.

Duplicate module names are reachable, and silent (backlog)

Two modules in the tree may hold the SAME name. Found on the bench: a classic ESP32 had a MoonLiveLayout and a MoonLiveEffect both called MoonLive, one under Layouts and one under a Layer. Nothing reported it. The UI keys a card's controls by module name, so both cards resolved to the same entry and the effect's bpm/zoom sliders rendered under the LAYOUT's heading, where its own petals/radius should have been. The server data was correct throughout; only the display was wrong, which is what makes it hard to recognise.

Scheduler::ensureUniqueName exists and is called on /api/modules creation and after a persistence load, so the tree normally cannot reach this state. The bench pair predates that pass or arrived through a path that skipped it, which is exactly the case a check would catch. The gap is that nothing NOTICES: a name collision is tolerated silently rather than reported, and the first symptom is a UI showing another module's controls.

Fix: assert uniqueness after the persistence load and report a collision in the module status, so a device that reaches this state says so instead of rendering the wrong card. Renaming a module from the UI would also give a user a way out; there is no name control today.

Deleting a module by name removes the FIRST match (backlog)

DELETE /api/modules/<name> resolves through findModuleByName, which returns the first match in tree order. With a duplicate name (above) that is not necessarily the module the caller meant: on the bench, deleting the effect by name would have removed the layout, because the layout came first.

Noticed while repairing that device, and avoided only by reading the handler before running the request. It is latent rather than dangerous today, because duplicates are supposed to be impossible, but the two issues compound: the state that makes a delete ambiguous is the same state nothing warns about. Fix alongside the check above, either by refusing an ambiguous delete or by addressing a module by a path rather than a bare name.

HTTP file serving blocks the render tick (backlog)

HttpServerModule::handleConnection() serves large embedded files (app.js, style.css) with the blocking TcpConnection::write — a page load can briefly stall loop20ms. One-shot per load (lower priority than the per-tick preview issue, which is fixed). Fix: serve large HTTP responses through a resumable per-client cursor drained on tick20ms (the shape the preview and full-state sends use).

Generic control + state topics over MQTT — the automation escape hatch (backlog)

The MQTT bridge ships a semantic topic surface (<prefix>/on/set, brightness/set, hsv/set → the Drivers controls) sized for Homebridge/HomeKit, which need fixed, typed topics per accessory. That leaves everything else the web UI can reach — effect choice, layout, modifier params, palette-by-index — unreachable from a home hub. The ask that surfaced this: "expose the whole REST API over MQTT."

It's compatible with Homebridge/HA, because it's a second topic namespace, not a replacement. Homebridge only ever subscribes to the semantic topics it's configured for; a generic topic family sits beside them and a broker carries both. The two surfaces already share one apply-core — Scheduler::setControl(module, control, json), the same seam /api/control and IR funnel through — so a generic MQTT surface is that core under a different topic shape, honouring the module's own "MQTT is a transport, not new control logic" contract.

But "the whole REST API" over-scopes: of the routes (/api/control, /api/state, /api/system, /api/modules[/…], /api/dir, /api/file, /api/firmware/*, /api/reboot, /api/types, the /json/* shim, /ws), only two are genuinely pub/sub-shaped. The rest are request/response or bulk transfer and belong on REST:

• <prefix>/api/control/set ← {"module","control","value"} (the exact JSON /api/control takes) → applySetControl. The real win: any control on any module — the effect/layout/modifier/palette reach HomeKit can't express. The apply-core already validates (range / read-only / module-not-found via SetControlResult), so safety is free.
• <prefix>/api/state/get → publishes the /api/state JSON (retained). For dashboards (fps / heap / tick / current effect across a fleet), offline detection, and alerting — the monitoring half.

Explicitly out (no practical MQTT case, and wrong for the transport): - /api/file, /api/dir, /api/firmware/upload — kilobytes-to-megabytes of binary; MQTT is a small-message bus, REST already streams these correctly. - /api/modules add/delete/move/replace — stateful, order-sensitive pipeline surgery a human does once in the UI; an automation reshaping the pipeline is an anti-pattern (the Robust to any input guarantee makes it safe, not advisable). - /api/reboot — one narrow action; a single fleet-reboot topic is a mild nice-to-have, not "the API." - /api/types, /json/*, /, /ws, /api/firmware/url — discovery metadata, the WLED shim, the UI itself, the socket: static, already-served-elsewhere, or a different protocol.

Shape: ~15 lines routing into the existing applySetControl + a state publish; gate behind a generic API bool defaulting off, so a home user's broker isn't a remote-config backdoor and the curated HomeKit surface stays the clean default. Don't auto-generate a semantic topic per control — HomeKit/HA need stable typed topics; a generic palette/set whose meaning shifts per firmware breaks their discovery. Keep semantic topics hand-curated; let the generic pair be the escape hatch.

HA MQTT Discovery — SHIPPED. The device announces a retained JSON-schema light config to homeassistant/light/<id>/config (the Tasmota/ESPHome/Zigbee2MQTT pattern), so HA auto-creates a wired entity — gated on the haDiscovery control, with a Last-Will availability topic. This covered the "HA can't reach the device over MQTT" incidents. The generic-topics escape hatch above (the whole REST API over MQTT, for power-user scripting) is the remaining unbuilt piece; keep it coherent with the DevicesModule command half (Tasmota-MQTT / zigbee2mqtt as outbound control — the mirror of this inbound surface) and the LightsControl integration point.

Open question — Homebridge example maps both setBrightness and setHSV. In homebridge-mqttthing's lightbulb, HSV's value (V) already carries HomeKit's Brightness characteristic, so mapping both topic pairs may double-drive brightness (mqttthing's docs lean toward using one or the other). The MQTT § Homebridge example currently lists both, to show the device's full topic surface. Resolve on hardware: flash a board, run Homebridge + mqttthing with that config, and check whether the Home-app brightness slider misbehaves — if it does, drop the two brightness topics from the example; if not, it's a non-issue. (Flagged by CodeRabbit; parked here rather than changing the doc on an untested hunch.)

HA update entity via MQTT discovery — release check (open follow-up)

Discovery config + install command wiring — shipped. MqttModule now publishes a second HA-discovery component at homeassistant/update/projectMM_<mac6>/config (same haDiscovery gate, same MAC-stable id, same device card as the light), state on <prefix>/update/state, and subscribes to <prefix>/update/set. HA renders a "Firmware: " card in the diagnostic section of the device panel. An install command routes to platform::http_fetch_to_ota with the release-artifact URL built from the payload version + kFirmwareName (https://github.com/MoonModules/projectMM/releases/download/v<version>/firmware-<key>-v<version>.bin), reusing the same OTA task the /api/firmware/url route drives.

Still to build — device-side release check. installed_version and latest_version are equal today (both MM_VERSION), so HA renders the entity as up-to-date and the Install button is disabled. What's missing is a periodic poll of https://api.github.com/repos/MoonModules/projectMM/releases/latest: at boot (~30 s post-network-up) and every 24 h thereafter, fetch the release JSON, extract tag_name, and if newer than MM_VERSION call MqttModule::publishUpdateState() with the updated latest_version (the publish path is already there — only the caller is missing). ~2 KB per check.

Two blockers, both platform-layer: - platform::http_fetch_to_ota is OTA-shaped — it writes bytes into the next OTA partition; there's no general "HTTPS GET into a buffer" seam. A small platform::http_fetch_to_buffer(url, buf, cap, statusBuf, size_out) next to it — ~30 lines wrapping esp_http_client on ESP32, a libcurl / URLSession stub on desktop — is the right home for this. - JSON parsing on-device — the existing mm::json scalar helpers are flat and key-order-independent; a releases/latest payload uses a nested assets[] array which the current helpers don't walk. Either extend them (~30 lines to walk one level of array), or scan for the tag_name string directly with strstr for this one caller.

Once both land, add a ReleaseCheckModule (or a small extension inside NetworkModule / FirmwareUpdateModule — decide when building) that owns the poll timer + last-seen version cache and calls into MqttModule::publishUpdateState(). ~50 additional lines.

Testing

Additional test coverage (pending)

• Memory degradation cascade — the output-buffer allocation decision (no buffer for a lone identity layer; a buffer for ≥2 layers or any LUT layer) is unit-pinned (unit_Layers_container "Drivers allocates the output buffer only when…"), and LUT-vs-identity is pinned by unit_Layer_sparse_mapping. What's not pinned is the low-heap half of architecture.md § Degradation cascade: under heap pressure the LUT + driver buffer are skipped together (lutSkipped() true, forced 1:1), and below that the layer buffer reduces dimensions (halving to a 8×8 floor) rather than failing. The hook exists — unit_BlendMap already uses platform::setTestMaxAllocBlock to force allocation failure for the paging test — so a test could cap the block size and assert: (1) LUT+output buffer both skip and lutSkipped() flips, (2) the layer buffer shrinks to fit and never goes null. Pre-existing gap (predates multi-layer); the happy-path allocation contract is covered, only the OOM-degrade branch isn't.
• Per-step assertions in scenarios (a framework gap, not a scenario gap). A scenario step can assert TIMING and HEAP (bounds, contract) and the run asserts the final buffer, but it cannot say "after this step the fixture has 24 lights", "this module's status reports a compile error", or "the rendered output changed". So a migrated script step proves the pipeline still ticks, not that the edit did what it claims — the MoonLive scenarios walk break-and-recover cycles whose most interesting states go unasserted. Wants a small vocabulary (expect_lights, expect_status, maybe expect_pixel) added to both runners together: the desktop/live split is exactly what let write_file exist on one and silently no-op on the other. Raised by CodeRabbit against scenario_MoonLive_pipeline and scenario_MoonLiveEffect_controls; the sites are listed there, but the vocabulary has to exist first.
• UI page load time — scenario step measuring HTTP response time for /, /api/state, /api/system via the live runner. Verifies acceptable load time on ESP32.
• Module teardown memory — scenario that tears down all modules and verifies heap returns to pre-setup baseline. Confirms no lifecycle leaks.
• JavaScript test harness — vitest + jsdom for the browser UI: pure helpers in install-picker.js (isCompatible, parseFirmwaresFromAssets, relativeTime) and app.js's conditional-control DOM logic (syncVisibleControls — reconciles which control rows are rendered when a hidden flag flips). The C++/backend half of conditional controls IS unit-tested (conditional_controls.h + per-module tests pin the binding + hidden flag), but the UI re-render half is not — syncVisibleControls was the source of a real re-render-loop freeze (Network static-IP toggle) caught only on hardware. A jsdom test that builds a card, flips a control's hidden, runs the reconcile, and asserts the right rows appear/disappear (and that it converges — the unchanged→no-op fast path) would have caught it. Attempted and reverted (2026-06-17): stood up vitest + 13 passing tests for the install-picker pure helpers, but the high-value half (syncVisibleControls) needs either an app.js module seam or extracting its reconcile logic into a separate served .js (6 embed/route wiring edits for a firmware-served file). Judged not worth adding a whole Node/npm toolchain to a C++/Python repo to test ~3 small pure functions; the toolchain earns its place only once the syncVisibleControls DOM test (and a real body of JS logic) lands with it. Do it as its own focused branch, deciding the app.js seam first (it's already type="module", so extracting reconcileControlRows into a served file — wired through embed_ui.cmake + the two HttpServerModule routes like the other UI .js — is the clean shape). Pure-helper _test exports + the reconcile extraction are the two pieces; both were prototyped in that reverted attempt.
• Browser-level Improv automation (deferred) — moondeck/build/improv_smoke_test.py (added 2026-06-03) exercises the device-side Improv listener over plain serial; what's missing is the browser-side equivalent — Playwright driving Chrome's Web Serial, clicking through ESP Web Tools' install modal, filling the WiFi creds form, asserting PROVISIONED. Catches "ESP Web Tools changed its Improv handling in a way that broke our manifest format" failures the serial-only smoke test can't see. Hard to set up reliably (headless Chrome with Web Serial is finicky, needs a wired ESP32 in CI). Pick this up if a regression in the browser flow ever escapes the manual dev-environment test (preview_installer flash-ready mode at http://localhost:8000/).

Live full-suite run leaks state between scenarios (test infra)

run_live_scenario.py --module all runs scenarios in sequence against one device, and they share the live tree. Two scenario styles don't compose: - Canvas-preparing scenarios (scenario_modifier_swap, scenario_perf_light, scenario_perf_full) clear_children the containers and rebuild, then their cleanup leaves the tree bare. - Canonical-tree-assuming scenarios (scenario_GridLayout_resize, scenario_MoonModule_control_change, scenario_NetworkModule_mdns_toggle) are mutate scenarios that expect the boot tree (Grid / Noise / Multiply) to already exist and only tweak it.

Run a bare-leaving scenario before a tree-assuming one and the latter fails pre-flight ("references ids neither on the device nor added by an earlier step"). Each passes in-process (fresh tree per scenario — the authoritative gate) and live individually (after a clean boot); only the chained live run trips. Not a product bug — a consequence of the "scenarios own their state, no restore" model the canvas-preparing scenarios follow, which the older ones predate.

Fix options: (a) make every live mutate scenario clear+rebuild its own canvas (consistent with the newer ones) so order never matters; or (b) have the live runner reboot / restore the canonical tree between scenarios. (a) is the cleaner long-term shape. Until then, the in-process suite is the gate; live full-suite runs need a clean boot per scenario, or run scenarios individually.

Housekeeping

Hot path: move blocking work off the render callbacks (architecture)

-Wfunction-effects proves the render path really does block — these are not annotation gaps, they are synchronous I/O, allocation and lifecycle work reachable from tick(). Each needs the work moved to a worker or made resumable, so each is a design change rather than a lint fix. Confirmed by external review (CodeRabbit, PR #56).

tick() — every frame, the sharp ones: - PreviewDriver::tick — the socket half is FIXED (the pull-model transport only ARMS a message; every socket byte moves on the transport tick). What remains: buildCoordTable() resizes keptIdx_ and the staging buffer on a rebuild/adopt tick. Suppressed at the site with the reason. - ParallelLedDriver::tick — tickSync()/tickRing() reach busWaitIfBusy(), which spins for the DMA peripheral. Deliberate (the driver owns the bus for the frame) but blocking. Suppressed. - Drivers::tick — joins/stops the render-split worker synchronously on the timed-out recovery path. Wants asynchronous handling that still preserves buffer ownership. - HueDriver::tick / tick1s — synchronous HTTP (pushOneChangedLight, pollPairing, fetchLights, fetchGroups) plus allocation. Wants a queue to a worker. - Layer::tick — calls applyState() on a modifier rebuild, which runs prepare/release and resizes ScratchBuffers. Wants the rebuild deferred to the scheduler's non-render prepare path, keeping today's coalescing of consumeNeedsRebuild(). - DemoReelEffect::tick — advance()/swapTo() create, delete and applyState() child effects from the render callback. Wants a pending-switch flag consumed off-tick. - NetworkSendDriver::tick — sends inline; wants to enqueue. - RmtLedDriver::tick — waits on hardware completion and reset; wants polling or offload. - AudioService::tick — UDP sendTo/recvFrom every frame (syncSend, syncReceive, syncEnsureSocket).

tick20ms() / tick1s() — milder, same shape: - HttpServerModule::tick20ms — inline handleConnection transport work, so the 100 ms budget cannot actually bound it. Wants resumable connection handling. tick1s writes WLED state frames inline; wants the existing resumable sender. - MqttModule::tick1s — synchronous DNS + discovery-buffer allocation. - NetworkModule::tick1s — WiFi/AP lifecycle transitions and tree rebuilds. - FilesystemModule::tick1s — the debounced flush() does filesystem work; the poll itself is fine, the save wants a worker. - FileManagerModule::tick1s — platform::filesystemUsed(); wants a cached value. - SystemModule::tick1s — the P4 coprocessorWifi() path calls esp_hosted_get_coprocessor_fwversion() synchronously; wants a cached snapshot. - ImprovProvisioningModule::tick — runs the queued APPLY_OP inline; wants a cold task to execute and publish only the result. - Scheduler::tick — dispatches all of the above, so its own contract is only as good as theirs.

Explicitly NOT in scope: the float-math findings (BouncingBallsEffect, RipplesEffect, SphereMoveEffect). Review suggested fixed-point, but the float trajectory IS the ported MoonLight behaviour and fidelity is deliberate. If the FPU-less Xtensa cost is real, that is a profiling question first, not a lint fix.

-Wfunction-effects reports these but never fails a build, and docs/metrics/hotpath-baseline.txt freezes the known set so a NEW blocking call stands out in the report. The pre-commit gate runs the same check incrementally.

ESP32 clang/LLVM toolchain — extend the clang checks to src/platform/esp32/

Espressif ships an xtensa LLVM (their fork), but the installed esp-clangd package contains only clangd — no clang++ driver — so a clang analysis pass over ESP32 sources needs their full LLVM installed separately.

What it would buy: -Wfunction-effects (and clang-tidy, clang-query) over src/platform/esp32/ — 20 translation units, the only code the desktop build excludes. Everything else, including the LED drivers, already compiles on desktop and is already checked.

What it costs: a second ~1 GB toolchain, maintained purely for analysis — the firmware would still be built by GCC, so the analysing compiler is not the shipping compiler. That is a real "one rule, one owner" tension, and the reason this is a decision rather than an obvious yes.

Worth revisiting when either the coverage gap bites (a hot-path bug traced to the platform layer that the desktop check could not see) or Espressif's LLVM becomes the default toolchain.

lizard: 94 functions are measured under a mis-parsed name (baseline can't pin them)

lizard's C++ parser loses the function name on certain bodies and falls back to the first keyword or cast it meets inside, so mm::SolidEffect::tick is reported as mm::SolidEffect::static_cast<lengthType> and mm::NetworkModule::tick1s as mm::NetworkModule::switch. Measured across src/: 94 of 2404 functions carry such a name (if 47, for 41, static_cast 5, switch 1), of which 10 are over threshold and therefore reach the report.

The consequence is the part that matters. whitelizard.txt matches by NAME, so those entries pin nothing: 35 of 162 baseline lines name a function lizard no longer produces. Each is a function whose complexity is now unmeasured against the baseline — real growth in it would either surface as a spurious "NEW violation" under the fallback name, or not surface at all. The check currently reports FAIL — 9 NEW on an unmodified tree for exactly this reason, which trains the reader to ignore the number.

It is not a threshold problem and not fixable by re-baselining: re-running --baseline just freezes today's fallback names, which shift again the moment a line moves inside the body. Real options, in order of preference: key the baseline on file:startline-anchored identity or lizard's long_name instead of name; pre-process so the parser keeps the name; or replace lizard's C++ front end with a clang-AST-based complexity pass (check_clang_query.py already has the AST machinery, so the metric could move there and drop the dependency entirely). Sizeable enough for its own /plan.

clang-tidy: triage the remaining 30 findings

.clang-tidy runs * minus a documented disable list and reaches zero on everything except the path-sensitive clang-analyzer-* family: 30 findings, led by bugprone-unchecked-string-to-number-conversion (9), security.insecureAPI.strcpy (5), core.NonNullParamChecker (4), deadcode.DeadStores (3) and unix.cstring.NullArg (3). Roughly half sit in test code (strcpy into fixed local buffers, a deliberate divide-by-zero probe).

The nine unchecked-string-to-number-conversion sites were read individually and are all safe: HueDriver guards on if (id > 0), JsonUtil documents 0-means-absent, MqttModule uses a v = -1 sentinel and clamps. They stay reported rather than suppressed — a report shows the real situation, and a NOLINT would hide a genuine class of bug for the next person who writes one of these.

These surfaced late for an instructive reason: the report parser's check-name pattern rejected the ,-warnings-as-errors suffix clang-tidy appends when WarningsAsErrors is set, so every finding was silently dropped the moment the ratchet was switched on. Fixed; recorded here because it is the sixth silent-zero this tooling has produced, and each looked like a clean tree.

WarningsAsErrors stays empty: clang-tidy reports, it does not gate (testing.md § Static analysis).

Heap-allocate the registerType<T> boot probe (lift a per-module lesson into core)

ModuleFactory::registerType<T> stack-constructs a T probe at boot to capture sizeof(T). On the main task's ~8 KB stack, a module with large inline members can overflow it and bootloop — a lesson the code records per module as a comment rather than fixing once in core: GameOfLifeEffect (an inline array here caused a P4 stack-overflow bootloop), HueDriver (the lightsBuf_ stack-probe lesson), and AudioService still carries ~5 KB of inline scratch while being factory-registered. This is the Complexity lives in core "lift the rule into core, don't paste it per module" clause: heap-allocate the probe (MoonModule::operator new already routes to PSRAM), or capture sizeof without constructing at all, so no module author ever has to remember the stack budget. Flagged by the 👾 Reviewer on PR #43. Small, core-only, its own /plan.

Migrate HueDriver's name buffers to ScratchBuffer (finish the ScratchBuffer sweep)

HueDriver::ensureNameBuffers() / freeNameBuffers() is the alloc-in-build / free-in-release / null-guard bundle that ScratchBuffer absorbs — and it does no dynamicBytes accounting, so the module's memory readout under-reports its Hue-light name buffers. It was skipped in the ScratchBuffer migration (its buffers are char[] name tables, not the grid-sized state the sweep targeted). Now that DriverBase::release() chains to MoonModule::release() (fixed on PR #43), a ScratchBuffer member here would free correctly on disable and self-report its bytes. Mechanical, one-file, behaviour-preserving. Flagged by the 👾 Reviewer on PR #43.

Socket-pair fixture for HttpServerModule WS-send tests (test infra)

HttpServerModule's resumable preview send (sendBufferedFrame / drainPreviewSend / cancelBufferedSend, the newest-wins drop, the per-client cursor over [hdr ++ body], the memory-adaptive chunk) has no direct unit test because driving it needs real TcpConnection clients whose writeSome returns partial / WouldBlock under control — and there's no socket-pair test fixture today. The send contract is covered indirectly: unit_PreviewDriver drives a CaptureBroadcaster mock for route-to-buffered / gate-on-idle / cancel-on-rebuild, and the live device sweep exercises the real drain across ticks. A loopback socketpair() fixture on the desktop platform (a TcpConnection pair where the test reads the bytes the server pushed, and can simulate a stalled receiver by not draining) would let the drain/drop/cancel/over-push paths be pinned host-side. Build it when the next core transport change lands (it'd also serve future WS tests).

Adopting the v6.x ecosystem changes (plan)

The as-is state of each item is the table in building.md § Adopting the v6.x ecosystem changes; this entry carries the plan and the triggers.

Per item, how and when:

• EIM — adopt any time. It shipped in v6.0 so it clears the v6.0-floor rule, and it has a headless CI mode. Add EIM as the preferred path in setup_esp_idf.py (eim install), keep install.sh as a documented fallback for one release. Keep the exact-commit pin: EIM's multi-version management helps reproducibility, it does not replace the pin.
• PSA Crypto — nothing to migrate while we stay on high-level components. Watch only: if a feature needs hashing or signing directly (signed-OTA verification, a device identity), write it against the PSA API from the start, not legacy mbedTLS. Trigger: first direct crypto use.
• network_provisioning — adopt to close the phone-app + SoftAP gap. It is in v6.0 (clears the floor) and is the IDF-native standard. Add it as a sibling provisioning module beside ImprovProvisioning (both wired-by-code System modules; a device offers whichever transports its chip supports), reusing the same WiFi-credential plumbing. Not a replacement for Improv: they cover different front-ends (browser vs phone-app) and a product can want either. Weigh the BLE-stack cost per chip. Spec before code.
• CMake Build System v2 — watch until GA, not while it is a preview: adopting a preview build system is the opposite of common-patterns-first. Trigger: v2 ships as the default. Then dry-run a build under v2, fix any idf_component_register() / Kconfig fallout, switch. Low risk given how little custom CMake we have.
• Built-in MCP server — evaluate, do not default to it. The risk is a second control path bypassing the script policy, and it is ESP32-only (no desktop), so it cannot be the uniform path. If adopted, wrap it behind a script (moondeck/run/idf_mcp.py) so the policy layer still applies. Trigger: a concrete debug workflow the scripts cannot cover.

Sequence. Close the v6.0 gaps one at a time as normal feature commits:

1. EIM installer — rework setup_esp_idf.py to prefer eim install, keeping install.sh as a one-release fallback. Smallest and lowest-risk (build-path only, no firmware change, no hardware re-test), and EIM's multi-version management is what cleanly supports the v6.0-floor / v6.1-fallback juggling, so it sequences first as an enabler.
2. network_provisioning — the headline capability: the phone-app + SoftAP onboarding flow. Its own plan.
3. The rest (PSA-native crypto, CMake v2, MCP) as their triggers fire.

Guardrails. Platform-generic stays intact: these are ESP32-specific gains and none may regress Teensy or the desktop paths, which do not use ESP-IDF at all. An IDF feature is adopted inside the ESP32 platform layer / build tooling, never by leaking an IDF assumption into shared src/ or the desktop build. And the v6.0 floor holds: adopt only what is in v6.0, so the v6.0 fallback keeps working.

ESP-IDF version pinning (pending)

The build IDF is v6.1-dev-399-gd1b91b79b5, a dev-branch snapshot (2025-11-05) ahead of the v6.0 stable but on the unreleased v6.1 line. The version facts (what v6.0 vs v6.1 changed, the release schedule, the 30-month support policy, how to check for a newer tag) live in building.md § ESP-IDF version; this entry tracks only the open decisions the doc doesn't make. Being on a dev branch already cost us once — the missing ESP_ROM_ELF_DIR in the post-build gdbinit step (fixed in build_esp32.py). Partly landed: setup_esp_idf.py carries PINNED_IDF_COMMIT/PINNED_IDF_VERSION and warns on drift (installed HEAD vs pinned) — it can't checkout for you (it doesn't own the clone), but a silent git pull or a stray shallow clone is now visible. Still to do: (a) a MoonDeck UI banner / status dot surfacing the same drift (the CLI warning only shows during Setup), and (b) the migrate-or-stay call — stay on the pinned commit (chosen for now: it's what all targets incl. P4 were validated against), or move to v6.1 stable (skipping v6.0, since v6.1 is close); migration is a full re-validation pass across classic/S3/P4, a deliberate task, not a pull. Until then: don't git pull the IDF. Schedule note: the v6.1-stable target of 2026-07-31 is unlikely to hold — v6.0 slipped ~1 month (planned 2026-02-27, shipped late March), and Espressif minors historically slip 2-6 weeks on the final even when betas land on time. So migrate to the event (v6.1 stable actually tagging on the releases page), not to the calendar date. v6.0 stable is the lower-risk fallback if the dev-branch warts (ESP_ROM_ELF_DIR, API-churn risk) get worse before v6.1 lands.

Clock sync — a shared monotonic clock across devices (committed design, unwired)

The second half of the core multi-device runtime; discovery ships, this does not. The design: one leader broadcasts its elapsed time (millis); followers compute their offset, targeting sub-millisecond accuracy. A shared monotonic clock is the foundation any cross-device coordination builds on, which is why it is core rather than light-domain.

The light-domain payoff is a wall of controllers animating in lockstep: effects already animate off elapsed time, so feeding them the leader's synced clock instead of each device's local one is the whole change on the render side. Device-to-device light distribution is a separate topology question and rides the existing ArtNet / E1.31 / DDP standards rather than a bespoke protocol.

Config provenance: firmware/MCU → deviceModel (catalog follow-ups)

The model itself is now a shipped design; see architecture.md § Config provenance (deviceModel is the one provenance level, the txPowerSetting example, and "default only where the hardware actually fixes it"). The catalog that carries it is mooninstaller/deviceModels.json (schema). The remaining forward-looking pieces — a devices.json/MCU-layer split and annotated-pin images — stay gated by the sequencing rule (no catalog field ahead of a consumer).

Persistence overlay: partial-save / schema-change audit (backlog)

The absent-key fix (json::hasKey guard in applyControlValue, so a saved file omitting a key no longer zeroes the control's default — the P4 ethType no-DHCP root cause) closed the acute hole. A broader audit would harden the overlay against the rest of the schema-drift surface, now that controls carry meaningful non-zero defaults: - Type-change safety (not migration — see ADR 0013). ethType changed int16 → uint8 (Select). A persisted file written under the old type still loads (the flat parser reads the number either way, and Clamp snaps an out-of-range value to the new bounds). The task is to confirm each type transition degrades gracefully through the robust loader (absent → default, stale → clamp, unknown → ignore) — especially Text/Password/IPv4 buffer-size changes — NOT to add migration code. A transition that would lose data silently is documented as a break in ADR 0013, per the settled policy. - Test coverage. unit_Control_apply_absent_key pins the absent-key contract; extend with a type-change round-trip (save int16, load into uint8 Select) and a narrowed-range clamp case so a future schema change can't regress silently. This is hardening, not a known bug — the shipped fix is correct for the cases that occur today.

ESP32-P4 support — rounds 3-4 (in progress)

Rounds 1 (board + Ethernet-only) and 2 (Parlio LED driver) have landed. Remaining rounds, each its own plan + commit: - Round 3 — WiFi via the C6 co-processor. WORKING, BUT THE LINK IS SLOW (2026-08-19). Boots and associates on IDF v6.1-rc1 (see round 4); the remaining defect is throughput, bench-bisected below. The P4 has no native radio (SOC_WIFI_SUPPORTED absent); WiFi comes from the on-board ESP32-C6 over SDIO via esp_wifi_remote / esp_hosted. Landed as the esp32p4rev1-eth-wifi firmware variant: components pulled P4-only (rules: gate in idf_component.yml), and ensureWifiInit() needs no hosted bring-up of its own: esp_hosted self-initialises at boot via a constructor (ESP_SYSTEM_INIT_FN), which sets up the SDIO transport, RPC and wifi-remote channels before app_main. Calling esp_hosted_init/connect_to_slave there would be worse than redundant — connect_to_slave is a transport reconfigure that resets the slave and re-inits SDIO, which fails on a live link. The rest of the WiFi seam is unchanged because esp_wifi_remote is API-compatible. A deliberate, documented v6.0-floor exception; C6 config via CONFIG_SLAVE_IDF_TARGET_ESP32C6 + CONFIG_ESP_HOSTED_CP_TARGET_ESP32C6 + the CONFIG_ESP_HOSTED_P4_DEV_BOARD_FUNC_BOARD SDIO-pin preset.

Hardware results (bench, P4-NANO, 2026-06-12): - ✅ esp_hosted / C6 SDIO comes up at boot. host_init: ESP Hosted, H_API: ESP-Hosted starting, add_esp_wifi_remote_channels, H_SDIO_DRV: sdio_data_to_rx_buf_task started. No NVS error / assert / panic / hang. Device boots fully (~57-60 FPS), hasWiFi true, WiFi controls present. esp_hosted self-initialises at boot via a constructor (ESP_SYSTEM_INIT_FN → esp_hosted_init), so no bring-up code is needed in our platform layer — an earlier explicit esp_hosted_init + esp_hosted_connect_to_slave prelude was removed: init was a redundant no-op and connect_to_slave is actually a transport reconfigure (slave GPIO-54 reset + SDIO re-init). SDIO config confirmed correct on the wire: CLK[18] CMD[19] D0[14] D1[15] D2[16] D3[17] Slave_Reset[54], 4-bit 40 MHz. - ❌ WiFi STA connect fails on the SDIO re-init. The cascade DOES fire correctly (Ethernet no link, cascading → STA path), but esp_wifi_init() (forwarded to esp_wifi_remote) internally triggers esp_hosted_reconfigure → Reset slave using GPIO[54] → sdmmc_card_init failed (×15) → card init failed → esp_wifi_init failed: ESP_FAIL. So: the boot-time SDIO init succeeds, but a runtime slave reset can't re-establish the SDIO link. The C6 doesn't come back after the GPIO-54 reset during operation. This is an esp_hosted/SDIO/C6-slave-firmware level issue (reset timing or slave image), below our application code — the pins and Kconfig are correct.

Open issues before this is done:

1. The esp_hosted build is slower on HTTP — BISECTED to the hosted link, not to us (2026-08-19), and much improved but NOT gone (re-measured 2026-08-21).

   Re-measurement on IDF v6.1-rc1, same board, same commit, same Ethernet interface, same method:

   build	per-request (/api/system)	throughput (76 KB app.js)
   esp32p4rev1-eth	10 ms flat	1,973 KB/s
   esp32p4rev1-eth-wifi	40 ms typical, one 280 ms outlier in 12	~980 KB/s

   So the penalty is now 4x per-request and 2x throughput, against 33-60x and 17x when this was written, and the alternating 0.4/0.8 s pattern is gone (one outlier in twelve, not every other request). Render is healthy in both (359 fps on the WiFi build). Something between the two IDF versions fixed most of it; what remains is the same shape (per-request, not per-byte) and still worth closing. The original measurement follows.

   Original (2026-08-19): Same board, same commit, same application code, measured over Ethernet on both builds so the radio is not in the path:

   build	per-request (/api/system)	throughput (73 KB app.js)
   esp32p4rev1-eth-wifi	alternating 0.434 / 0.788 / 0.446 / 0.813 s	42 KB/s
   esp32p4rev1-eth	13 ms flat, 12 consecutive fetches	708 KB/s

   Render is healthy in both (121-134 fps), so this is not frame-loop contention. Because the two images share every line of application code, the penalty is esp_hosted being compiled in and its SDIO link serviced, degrading traffic on an interface it is not even carrying. The cost is per-request, not per-byte (a 1 KB fetch cost nearly as much as a 36 KB fetch), which points at a periodic blocker a request must wait out rather than a slow pipe.

   Already excluded on the bench: SDIO width/clock (already 4-bit/40 MHz, the maximum), WiFi buffer counts (match the S3's), ICMP latency (6.6 ms). An earlier SystemModule fix (coprocessorWifi() retried an unanswered version query every tick: 1,012,344 us → 257 us) was real and is kept, but it was not this: the stutter outlived it and vanished only when the C6 path left the image.

   Per-module tick timing, both builds on the SAME Ethernet interface (2026-08-19). The measurement that says what this is NOT:

   module	eth-only	eth-wifi	factor
   HttpServer	113 us	3441 us	30x
   File Manager	279 us	4686 us	17x
   Services	242 us	1388 us	5.7x
   Audio	239 us	1376 us	5.7x
   Effects	172 us	397 us	2.3x
   Network	10 us	92 us	(negligible in absolute terms)
   Drivers	6601 us	4215 us	0.64x (FASTER)
   ParallelLed	7186 us	6569 us	0.91x (faster)

   Two theories are refused by this table. It is not a blocking WiFi call in NetworkModule (Network costs 92 us, and wifiStaRssi/wifiTxPower are state-gated off entirely in ConnectedEth); and it is not periodic WiFi scanning, since no module carries anything like a 0.37 s cost. Instead modules that touch no network at all (Audio, Noise, Effects, Layer) slow by the same kind of factor as the HTTP path: a broad, roughly proportional slowdown of ordinary code.

   Working theory: L2 cache contention. Both builds are byte-identical in every memory setting (CACHE_L2_CACHE_128KB, SPIRAM_SPEED_200M, FLASHFREQ_40M, SPIRAM_MODE_HEX — a full sdkconfig diff shows no cache/PSRAM/flash/CPU-freq difference), and code executes from flash through that shared 128 KB L2 in both. Adding esp_hosted's tasks, ISRs and DMA buffers evicts application code that was previously resident, so ordinary work starts missing to flash/PSRAM. This also explains the otherwise odd inversion: the DMA-bandwidth-bound Drivers/ParallelLed got faster, which is what happens when the CPU competes less for the same bus. Consistent with the data, not yet proven — separating cache contention from plain CPU stealing needs a cache-hit-rate counter or a per-tick histogram, neither of which we expose today.

   The cache theory does NOT explain the visible LED hiccup, and there are TWO effects here (PO observation, 2026-08-19). Uniform cache contention predicts a smooth frame-rate drop (133 → 96 → ~73 fps), which is what the averages show. It does not predict a stall, yet a once-per-second hiccup is plainly visible on the fixture. So the throughput loss and the hiccup are separate problems and must be chased separately.

   Our instrumentation structurally cannot see the hiccup. MoonModule::tickTimeUs_ is a MEAN (accumUs_ / frameCount, MoonModule.h:656) and Scheduler::fps() is derived from it, so a single 300 ms frame among 70 good ones shifts the average ~4 ms and vanishes. Every per-module number in the table above is an average and none of them can confirm or refute a stall. External evidence of the stall is therefore weak but non-zero: sampling fps once per second for 30 s gives a steady 73 with periodic dips to 69-70 (~55 ms lost in those seconds), and the dips are NOT on a clean 1 s period. Ruled out along the way: the degradation is not caused by our own HTTP polling (fps is identical at 76 after 25 s of zero traffic and under continuous polling), and the early 96 → 73 decay is warm-up, not load.

   Per-TASK CPU, both builds, --task-cpu-stats (2026-08-19) — this is the decisive measurement. Same profiling overhead on both, so the comparison is clean:

   task	prio	eth-only	eth-wifi
   main (render)	1	35.4%	93.3%	the same work costs 2.6x the CPU
   IDLE0	0	63.3%	5.1%	core 0 headroom is gone
   ipc1	24	7.8%	12.7%	present in BOTH, so not the cause
   mmEncode	5	3.4%	6.0%
   sdio_read / sdio_write / sdio_process_rx / rpc_rx / rpc_tx	23	absent	0.0-0.1%	the hosted tasks are IDLE

   What this refutes. Not a busy WiFi task: every SDIO/RPC task sits at 0.0-0.1%. Not periodic WiFi scanning, and not a blocking call in our render path either, since main is not waiting — it is running, and burning 2.6x the cycles for identical work. Not ipc1 (priority 24, preempts everything), which is present on the eth-only build too. There is no WiFi activity to stop, so a "compile it in but don't run it" variant would likely change nothing; the cost is already there with the link idle.

   What this supports. The same instruction stream executing 2.6x slower with no extra runnable work is the signature of memory contention, consistent with the L2-cache theory above: esp_hosted's footprint evicts application code from the shared 128 KB L2, so ordinary code stalls on flash/PSRAM fetches. Cycles are spent inside main, which is why every module slowed proportionally and why the DMA-bound drivers (bandwidth-bound, not cache-resident) got faster.

   Still unexplained: the visible ~1 s LED hiccup. Cache contention predicts the steady 2.6x, not a stall. Per-task CPU is cumulative-since-boot and cannot show a spike either. So the hiccup remains unmeasured, and the worst-case instrumentation below is still the next step for it specifically.

   Instrumentation gap to close first — worst-case tick tracking. Add a per-module and per-scheduler max (and ideally a coarse histogram or a "frames over 2x mean" counter) alongside the existing mean, and expose it in /api/system. Cheap (one comparison per tick), and it converts "the PO can see a hiccup that no number shows" into a measurable quantity. Without it, every theory below is unfalsifiable from the host side. Reading the P4 console needs CONFIG_ESP_CONSOLE_USB_SERIAL_JTAG=y or a UART adapter on GPIO 37/38 (see the dev-loop note in round 4), so serial is not the fast path.

   Then, cheapest first: (a) read the new max/histogram to see whether the cost is uniform or spiky (uniform favors cache contention, spiky favors a blocking call, and the two coexisting is now the leading reading); (b) the P4 cache performance counters for a direct miss-rate read; (c) moving the hot render path to IRAM/internal RAM and re-measuring, which is also a candidate fix rather than only a diagnostic. 1. Runtime SDIO re-init of the C6 fails — CONFIRMED a C6 slave-firmware problem (not a guess). SystemModule now exposes a wifiCoproc read-only control (via platform::coprocessorWifi() → esp_hosted_get_coprocessor_fwversion()), and on the bench it read not detected at the time (the control now reports no version reply, and only after a bounded number of attempts): the C6 returns no valid firmware version. What that means was overstated here. It was read as the signature of absent / incompatible slave firmware, but the same board later associated and served traffic over that very link while this RPC still went unanswered — so an unanswered version query says the QUERY failed, not that the C6 is absent. The round-3 conclusion below rests on the sdmmc_card_init failed re-init evidence, not on this control. Likely a version mismatch on top of that: The host pulled esp_hosted 2.12.9; Espressif's P4-Function-EV-Board ships its C6 pre-flashed with esp_hosted slave v0.0.6, and the Waveshare NANO is a different board that may carry a different / absent C6 slave image. The symptom fits: boot inits the host SDIO master fine, but resetting the C6 (GPIO 54) and re-enumerating it as a slave fails (sdmmc_card_init failed) because the C6 has no compatible slave firmware responding. Primary next step: build + flash the version-matched esp_hosted slave firmware onto the NANO's C6. The slave project is already vendored at esp32/managed_components/espressif__esp_hosted/slave/ (sdkconfig.defaults.esp32c6, partitions.esp32c6.csv); idf.py create-project-from-example "espressif/esp_hosted:slave" → set-target esp32c6 → flash. Caveat / needs PO + bench hardware: flashing the C6 on the EV board uses an ESP-Prog wired to the PROG_C6 header with the P4 held in bootloader mode (esp_hosted docs/esp32_p4_function_ev_board.md §5.2) — the NANO's C6-flash path must be confirmed (separate USB? equivalent header? ESP-Prog?), and an ESP-Prog may be needed. An OTA slave-update path exists but needs a working link first (chicken-and-egg here). This is a hardware-provisioning task, not application code. Secondary fallbacks if firmware-match doesn't fix it: an esp_hosted option to skip the reconfigure/slave-reset when the transport is already up at boot; a slower SDIO freq or 1-bit mode; verify GPIO 54 reset polarity/timing for the NANO. (Note: EIM — the building.md v6.0-adoption item — does NOT help here; it's a host-machine installer, unrelated to device-side C6 firmware.)

User lead (2026-07-09) — avoid the WiFi teardown/re-init on hosted targets entirely; it may sidestep the slave-reset failure. A user hit the mirror symptom on a different codebase (ESP32-Sveltekit / WLED-MM, not projectMM — its lib/framework/WiFiSettingsService.cpp doesn't exist here): after a clean C6-flash the P4-NANO WiFi worked, but their app's boot-time WiFi.disconnect(true) fully tore down the WiFi stack, and the later AP bring-up then failed with esp_hosted_transport_config: Transport already initialized / esp_hosted_init failed! / AP enable failed!. Their working fix: on CONFIG_ESP_WIFI_REMOTE_ENABLED (= hosted) targets, don't do a full stack reset — keep STA enabled, reconnect without a full teardown/re-init, and never call WiFi.disconnect(true) in the disconnect callback. Why this is relevant to us even though the file differs: our own comment at platform_esp32.cpp:796 already documents that the esp_hosted transport is set up once at boot and is fragile to re-init (connect_to_slave = a transport reconfigure that resets the slave + re-inits SDIO and fails on a live link). Our disconnect callback is already safe (wifiEventHandler on STA_DISCONNECTED only sets a flag — no teardown), BUT our failover path is not: wifiStaStop() (platform_esp32.cpp:915) calls esp_wifi_deinit(), and the STA-retry / AP-fallback then re-runs ensureWifiInit() → esp_wifi_init() — the exact deinit→reinit cycle that on a hosted target triggers the GPIO-54 slave reset (round-3 open-issue #2's sdmmc_card_init failed). So the round-3 failure ("runtime SDIO re-init of the C6 fails") and this user's report may be the same root cause: the re-init shouldn't happen at all on a hosted target. Concrete next step to try on the bench: guard the teardown/re-init on platform::hasWifiCoprocessor (already defined = isEsp32P4 && hasWiFi) — on hosted targets, do NOT esp_wifi_deinit() in wifiStaStop() and do NOT re-esp_wifi_init() in ensureWifiInit() once the boot-time init is up; instead just esp_wifi_disconnect() + esp_wifi_set_config() + esp_wifi_connect() (STA retry) or esp_wifi_set_mode(APSTA) for the fallback, reusing the live transport. This is cheaper than the C6 reflash and independent of #18759, so it's worth trying first once the board boots. If it works, it also removes the slave-reset from the normal failover, not just the AP case. Blocked behind the #18759 boot crash like everything else P4-WiFi, but this is the first thing to try when the board boots again. 2. Co-processor components no longer compile into esp32p4rev1-eth — FIXED. The gate is now rules: if "$CONFIG{MM_P4_WIFI} == True" (the $CONFIG{NAME} form, no CONFIG_ prefix inside the braces — the bare form silently skipped the dependency, see round 4 below) (a Kconfig option declared in esp32/main/Kconfig.projbuild, set only by sdkconfig.defaults.esp32p4rev1-eth-wifi), so esp_hosted / esp_wifi_remote are pulled only by the WiFi build, never by eth-only. The old target == esp32p4 gate pulled them into esp32p4rev1-eth too; that wasn't merely build-time waste — esp_hosted self-inits its SDIO master at boot, which on the eth-only build interfered with the EMAC bring-up (a red herring chased during the P4 no-DHCP hunt). The eth-only image dropped 1.36→1.12 MB once gated out. The wifiCoproc read-out stays compile-gated on platform::hasWifiCoprocessor (isEsp32P4 && hasWiFi). 3. Build reproducibility. build_esp32.py does not yet build this variant reliably: the C6 slave-target Kconfig default ... if IDF_TARGET_ESP32P4 only fires on set-target, and the reconfigure a plain build triggers drops it back to ESP32-H2 (no WiFi) → fails on missing CONFIG_WIFI_RMT_*. A clean manual sequence works (rm -rf <build dir> → set-target esp32p4 → build, all with the same -DSDKCONFIG/-DSDKCONFIG_DEFAULTS); the wrapper needs a fix so the auto-default sticks across reconfigures (see the KNOWN ISSUE comment in build_esp32.py).

Round 4 — the IDF-update regression (2026-07-03). After the IDF bump to v6.1-dev-5215-g0d928780081, the variant stopped building entirely, then stopped booting. Two distinct causes, both IDF/component-manager side (all our config was correct): - ❌→✅ Build: esp_hosted.h not found — the manifest if syntax changed. The component manager (now 3.0.3) silently skipped esp_hosted/esp_wifi_remote (NOTICE: Skipping optional dependency) because our idf_component.yml rule used the bare CONFIG_MM_P4_WIFI == True. The current manager only recognises a Kconfig variable in the $CONFIG{...} form (its KCONFIG_VAR_REGEX = \$CONFIG\{([^}]+)}); the bare CONFIG_X falls through to plain string-eval → false → skipped. Fixed: if: "$CONFIG{MM_P4_WIFI} == True" (note: NO CONFIG_ prefix inside the braces). Confirmed by idf-component-manager #104 + the official manifest docs. This also supersedes open-issue #3 above — with the correct syntax the pull is reliable (no set-target dance needed for the dependency). - ❌ Boot: sleep_clock_icg_startup_init aborts with ESP_ERR_NO_MEM (0x101) → reboot loop. A KNOWN, OPEN ESP-IDF bug: esp-idf #18759 (IDFGH-17859) — on ESP32-P4 + PSRAM, this sleep-clock retention init runs unconditionally at a SECONDARY boot phase (before app_main, NOT gated by CONFIG_PM_ENABLE) and fails to allocate its REGDMA retention links when early internal DRAM is tight, which it is once esp_hosted's SDIO stack is pulled in (WiFi build only; the eth-only P4 has DRAM to spare). Espressif's guidance on the issue: reduce early internal-DRAM static usage. Bench findings (2026-07-03): CONFIG_SPIRAM_TRY_ALLOCATE_WIFI_LWIP does NOT help (those buffers allocate after the boot init); CONFIG_PM_POWER_DOWN_PERIPHERAL_IN_LIGHT_SLEEP=y drops the ICG file but only moves the failure to the next retention alloc (PCR / int_wdt) then a sleep_retention.c:914 assert; .bss/.noinit → PSRAM (CONFIG_SPIRAM_ALLOW_{BSS,NOINIT}_SEG_EXTERNAL_MEMORY) still fails — because MALLOC_CAP_RETENTION is a specific reserved memory region, not general DRAM, so freeing general DRAM doesn't reach it. MoonLight ran the same board on IDF 5.5 without it, so it's a 6.1-era regression. RESOLVED for us 2026-08-19 by resolution path 1 below (CONFIG_PM_SLEEP_CLK_ICG_ENABLE=n on IDF v6.1-rc1) — a workaround, since the allocation failure is untouched and #18759 remains open upstream.

**Resolution paths (each independent):**
1. **Upstream fix — SHIPPED on master, needs a v6.1 back-port or a cherry-pick (rechecked 2026-07-27).** #18759 was marked **Done** on 2026-07-27 and has since been **reopened — it is OPEN upstream** (rechecked 2026-08-20; see the status note at the end of this item). The fix is exactly the knob we wanted: commit `7d31b82d27d` ("change(esp_pm): add kconfig option for REGDMA sleep clock ICG", 2026-07-06) adds **`CONFIG_PM_SLEEP_CLK_ICG_ENABLE`** (`bool`, default `y`) — set it **`n`** and the crashing `sleep_clock_icg_startup_init` is not built/run. Since a 236-FPS LED controller never light-sleeps, ICG retention is dead weight for us, so `=n` costs nothing. **But it is on `origin/master` only — NOT back-ported to `release/v6.1`** (our pinned IDF `14f663f`/dev-5880 and the current `origin/release/v6.1` are the same commit; neither has it). So bumping the pinned v6.1 IDF does *not* get it yet. **Decision (2026-07-27): wait for the next v6.1 beta** that carries the back-port, rather than cherry-pick `7d31b82d27d` onto the pinned IDF — a manual local IDF patch is bespoke, drifts, and complicates the single-pinned-IDF story for a fix that is a clean one-line sdkconfig change once it's in the branch. **DONE 2026-08-19 — that plan executed exactly as written.** v6.1-rc1 published carrying the option as `4b8e1e87106` (verified present in `components/esp_pm/Kconfig` at the pinned commit `44f0c59f7c8`); the IDF pin was bumped, `CONFIG_PM_SLEEP_CLK_ICG_ENABLE=n` added to `sdkconfig.defaults.esp32p4rev1-eth-wifi`, and the P4-WiFi boot bench-tested: it boots, associates (RSSI -52) and serves the UI. The variant is out of the installer's experimental set and ships as a normal firmware. Reported back on the upstream issue ([comment](https://github.com/espressif/esp-idf/issues/18759#issuecomment-5345660136)), which also told the original reporter the option had landed — nobody had announced it in the thread. **#18759 stays OPEN upstream** and we did not ask for it to be closed: the retention allocation still fails under early-DRAM pressure, the option merely means nothing requests that memory. Round 3 is now unblocked, and its remaining defect is throughput, not boot (see open issue 0 above).
2. **IDF 5.5 fallback — investigated 2026-07-03, NOT a cheap escape.** MoonLight ran this exact board on IDF **5.5** without the crash, so a 5.5 build of just this variant (everything else on 6.1) looked like a timeline-independent path. A bench attempt against IDF 5.5.4 found `src/platform/esp32/` has drifted to genuinely require IDF **6.x**: four distinct 5.5↔6.1 API breaks in `platform_esp32.cpp` / `platform_config.h` — (a) `RMT_LL_TX_CANDIDATES_PER_INST` renamed (5.5: `SOC_RMT_TX_CANDIDATES_PER_GROUP`); (b) `esp_eth_phy_ip101.h` moved (5.5: ctor lives in core `esp_eth_phy.h`, no standalone header); (c) `CHIP_ESP32S31` enum is 6.1-only; (d) `ETH_ESP32_EMAC_DEFAULT_CONFIG()` in 5.5 has out-of-declaration-order designated initializers — a C++ **hard error no compiler flag suppresses** (`-fpermissive` doesn't touch it). So a working 5.5 binary needs permanent `#if`-IDF-version compat branches in the platform layer (an EMAC-init back-port + a second IDF 5.5.4 in the CI matrix) — a real feature, not a throwaway. Only worth it if #18759 stalls long enough that a shippable P4-WiFi is needed sooner.
3. **Version-matched C6 slave reflash** (see round-3 item 1) — may change the boot memory picture, but is blocked behind the boot crash (host must boot to test the C6 handshake), so it only matters once 1 or 2 gets us to `app_main` stably.

• Round 4 — Parlio loopback self-test FIXED (2026-07-09), real long strip still to prove. The Parlio loopback self-test now passes on P4 hardware at any grid size (verified on MM-P4, jumper GPIO 32↔33, at both 8×8 and 128×128). A real long WS2812 strip (not just the bench panel) is the remaining hardware proof.

The bug it exposed (fixed): on IDF v6.1-beta1 the self-test failed bad bit 0/0 at large grids — it worked at 8×8 but not 128×128. Two stacked hardware limits, both hit only because the test built a frame sized to the whole operational grid: (1) the P4 Parlio has no DMA-EOF, so one non-loop transfer is hard-capped at PARLIO_LL_TX_MAX_BITS_PER_FRAME (~0.5 Mbit) — a 128×128 grid (~1.2 Mbit) is rejected outright with ESP_ERR_INVALID_ARG, so nothing transmits; and (2) even once the transfer fits, the shared RMT-RX capture can't hold a large symbol count (a big frame → rx captured 0 symbols). Both surfaced as the same misleading bad bit 0/0. A wrong first guess (an IDF sample_edge→shift_edge clock-edge rename) was tried on hardware and rejected — both edge values fail, ruling the edge out; the serial log (loopback: N bytes in …, rx captured 0 symbols) is what pinned the real cause. The fix: the self-test now caps its frame to a small fixed ParallelLedDriver::kLoopbackTestLights (256) instead of the operational grid — the test only needs to prove the peripheral emits correct WS2812 bits, which a few hundred lights exercise fully (encode → fused correct+transpose → single-shot DMA → latch pad), and 256 fits under both the transfer cap and the capture buffer on every parallel driver, so it runs identically at any grid size. Lesson: an on-device self-test must size its own probe to the peripheral's real limits, not to the user's configured output size. (This whole diagnosis is a good "verify against the working reference before concluding" case — the PO's memory that it had worked at fd6c1d8e is what redirected the hunt from "capability gap" to "regression".)

Loopback on the MHC-WLED P4 shield — RESOLVED: the header is not pure GPIO (shield builder confirmed, 2026-07-09). The shield's 4x-In/Out header (pins 46, 47, 2, 48; 46 & 2 are P4 boot straps per gpio-usage) never passed the continuity precheck: 46↔47 captured partial/corrupt (206 of 1536 symbols → bad bit 0/0); 47↔48 read jumper not detected even with the jumper seated. The mm_loopback continuity …: hi=%d lo=%d diagnostic read hi=0 lo=0 (no direct signal path). Shield builder (Wladi) confirmed the cause: the header has no pure GPIOs — outputs go through a level shifter, inputs through diode protection + a ~16 kHz low-pass filter (by design, for robust button-style inputs), so the raw drive-and-read continuity probe can't bridge it. Not a firmware bug and not fixable in software; the self-test needs a genuinely direct GPIO pair. Workaround for a real loopback test on the shield (Wladi's suggestion): drive the LED signal out one RS485 output, configure a 4th channel as an RS485 input, and jumper the two with cables — the signal is then readable on the respective GPIO. The frame-size fix itself is proven independent of this (MM-P4 NANO, direct 32↔33, PASSes at every grid). The loopbackJumperOk continuity read is kept as a permanent bench HAL diagnostic (it's what pinned this) — a hi=0 lo=0 result now has a documented meaning: a buffered/level-shifted header, not a direct GPIO.

Dev-loop note — reading the P4's runtime log over USB. The P4-NANO's primary console is UART on GPIO 37/38 (CONFIG_ESP_CONSOLE_UART_DEFAULT), not the USB port, so ESP_LOGI / mm_net lines are not visible over /dev/cu.usbmodem* by default — only the ROM boot banner and std::printf-to-stdout (which routes to the secondary USB-Serial-JTAG console) come through. Two workarounds when you need the runtime log over USB: (a) temporarily set CONFIG_ESP_CONSOLE_USB_SERIAL_JTAG=y (note the JTAG endpoint re-enumerates when the app starts, so a reader must reconnect across the drop — idf.py monitor handles it; a plain fixed pyserial handle dies); or (b) hang a USB-UART adapter on GPIO 37/38. This cost real time during the P4 no-DHCP hunt; the fastest signal there turned out to be a printf of the runtime struct (stdout → secondary JTAG console) plus a git worktree bisect (build an old commit, flash, check LAN reachability) to prove code-vs-hardware without needing the log at all.

WiFi runtime disable (backlog)

Compile-time answer already ships: --firmware esp32-eth excludes the WiFi stack. The default esp32 already cascades — ethInit() runs first, WiFi only comes up if no PHY responds — so a wired board never associates over WiFi. What's still missing is reclaiming WiFi's heap: even when Ethernet wins the cascade, esp_wifi_init's RX buffers stay allocated. This item skips that init entirely once Ethernet is up, freeing ~16 KB. Defer until the heap saving is worth the teardown-ordering risk.

UI

Forward-looking companion to the shipped UI spec, moonmodules/core/services.md. The live spec describes the UI as shipped; this file holds what is not in it yet: deferred items, open design questions for 1.0, and the gap analysis against projectMM v1. The backward-looking half (how v1/v2 actually worked, patterns consciously rejected, recorded quirks) lives in history/v1-inventory.md.

Deferred to 1.x

• Side nav with drag-reorder of root modules (root order is fixed in main.cpp today; not painful — and arguably correct, see the gap-analysis note below)
• Health panel (<details> + GET /api/test)
• Log panel (<details> + WS {t:"log",m:"…"})
• Core affinity badge (C0/C1) — only meaningful when core pinning lands
• Module category() field — taxonomy beyond role() for the picker (decision: derive from role() for now)

File Manager follow-ups

The shipped File Manager (see system.md) is a lazy expand/collapse tree over /api/dir + a size-capped text editor over /api/file, with drag-drop upload (tier 1) + per-file download + a filesystem-usage bar. Deferred capabilities, each self-contained:

• Upload — recursive folder tier. Single-file upload of any size streams to the file (fsWriteStream, binary-safe, kUploadMax + free-space guarded) and downloads stream back (fsReadAt), so text/config/binary all work. Remaining: multi-file / recursive folder drops — client-side mkdir + walk via dataTransfer.items webkitGetAsEntry().
• Download — folder as .zip. Per-file download streams (<a download> on /api/file). A folder download needs the browser to walk /api/dir recursively, fetch each file, and build a .zip client-side — which means bundling a zip library into app.js. That's a permanent app.js size bump, and app.js is embedded in firmware, so it weighs on the flash budget (see the flash-budget item above). Gate on real demand; symmetric with the folder-upload tier.
• Last-modified dates. Needs a time source (NTP) + LittleFS mtime storage; the tree is name + size until both land. Backlogged with the NTP work.
• .ml syntax highlighting in the editor. MoonLive source wants highlighting (a color layer over the textarea), not the JSON-style reformat — a bigger editor change (a highlight overlay or a small tokenizer), added when MoonLive .ml files land on disk. The editor already has an extension seam (fmPrettify) for the reformat case; highlighting is the separate, larger tier.
• Keyboard + screen-reader access for the tree. The fm-row tree entries are mouse-only today (click to select/expand/open). Making them keyboard-operable (focusable, Enter/Space activation) with ARIA tree semantics (role="treeitem", aria-expanded from isOpen, aria-level) is a real accessibility win but adds JS that lands in the firmware-embedded app.js (flash cost). Do it when a11y is a stated goal, together across the whole generic UI, not just this panel.

Open design questions

These don't block the shipped baseline but should be answered before 1.0:

• Multi-layer UI — architecture.md plans for N layers blended into one Drivers. The current card layout shows one Layer. Likely needs a tab/accordion to switch layers, or a per-layer column.
• Modifier chain visualization — show the modifier order visually. They're a flat list today, but the children[] order is the apply order now (modifiers compose as a chain, M₁∘M₂∘…), so a visual that conveys the stacking (and that order matters) would help users reason about a multi-modifier layer.
• Presets — save/load named bundles of control values. Persistence already stores them; needs a UI surface.
• Canvas/node-graph view — v2 attempted this. Powerful for complex setups but doubles the UI surface. A reasonable v3 follow-up gated on user demand.

Gap analysis — v1 features not yet in v3

Inventory of v1 frontend behaviours v3 lacks, with a recommendation each. Items already shipped (control types, dragTs, two-timescale inputs, type picker, theme, scroll-shrink preview, status bar, reset-to-default, fps/ms toggle, drag reorder, side nav + drawer + footer) are not repeated.

Legend: Adopt-1.0 (small, high value) · Defer-1.x (needs engine work or a feature we lack) · Drop (not needed).

Per-card features

v1 feature	v3 today	Recommendation
Header: setup-dot before name	name only	Defer-1.x — needs setupOk() + health() on MoonModule with a real failure mode. Today both would always be true / "".
Module ID shown separately from name	name only	Defer-1.x — add when instances need disambiguating (e.g. two effects of the same type under one Layer).
Category emoji badge on the card header	role emoji in the picker, not on the card	Defer-1.x — ROLE_EMOJI already exists in app.js; showing it per-card is a small step if card scannability needs it.
Core affinity badge (C0/C1)	core pinning not implemented	Drop until core pinning is a real engine feature.
Memory split heap vs PSRAM	static+dynamic shown on the card	Defer-1.x — splitting dynamicBytes further needs platform::isPsramPointer(p) or per-alloc tracking, neither exists yet.

WebSocket / panels

v1 feature	v3 today	Recommendation
Drag-to-reorder root modules (POST /api/modules/reorder)	not supported	Drop — root order is fixed in main.cpp and that's correct: Layouts/Layers/Drivers + system modules are mandatory and ordered. Children reorder via drag already.
Log channel {t:"log",m:"…"} pushed by server	no server log push	Defer-1.x — needs an engine-side log producer. Gate: when boot/network/persistence logs become interesting to non-developers.
Schema channel {t:"schema",modules:[…]} for tree-shape changes	full /api/state push every update	Drop — keep the full-tree push; re-evaluate only if WS bandwidth becomes a problem with large trees.
System health panel (polls GET /api/test, pass/fail table)	none	Defer-1.x — needs a runtime /api/test that runs the doctest suite; ctest covers this for now.
Log panel (ring buffer, severity coloring, stick-to-bottom, GET /api/log backfill)	none	Defer-1.x — pairs with the log WS channel; both arrive together.

Cost / decision table

Cost class	Items
Tiny (< 30 lines, no backend)	category emoji badge on the card header
Medium (minor backend change)	help-link mapping (needs docs site); richer category() than role()-derived
Large (separate plan)	health panel + /api/test; log panel + WS log channel; OTA + GitHub-update badge; full multi-layer UI; presets UI

GCC Release-mode truncation warnings (17, non-blocking)

uv run moondeck/build/build_desktop.py --gcc reproduces CI's compiler (CI builds Debug, and that is clean). Building the same tree Release with GCC surfaces 17 further -Wformat-truncation / -Wstringop-truncation / -Wstringop-overflow warnings in Control.cpp, HttpServerModule.cpp, JsonUtil.h, MqttModule.cpp — Release inlines more, so GCC can prove more about buffer sizes and gets stricter.

They are not CI failures (CI is Debug) and each one inspected so far is a false positive of the same shape: a bounds check exists, but GCC cannot prove the degenerate case (e.g. HttpServerModule.cpp:2400 warns "writing 1 byte into a region of size 0" on a line guarded by if (wsLen + headerLen > sizeof(hdr)) return false;). Still worth clearing: each is either a genuinely unprovable bound (fix the code) or a bound the code knows but does not state (make it explicit). Doing it in one pass beats letting them mask a real one later.

Not done with the multi-destination/tab-UI merge because 17 warnings across four core files is its own change, not a tail on someone else's.

MoonLive core/platform layering + JIT sdkconfig scoping (CodeRabbit #29, 4 findings)

Four 🟠 Major boundary findings from the PR #29 review are real but each is its own scoped change, not a tail on the ring branch. The Critical sibling (a cpl<3 overflow guard in the MoonLive effect's tick) landed with the branch it was found on; these four are backlogged:

• Core includes platform, compiled core in mm_core. src/core/moonlive/MoonLive.cpp #includes platform/platform.h and calls the exec-memory API directly, and the root CMakeLists.txt compiles MoonLive.cpp/MoonLiveCompiler.cpp into mm_core and links mm_core → mm_platform — violating the header-only-core / no-platform-includes contract both files declare. The runtime exec-memory placement layer wants a core-neutral injected interface (or to move out of src/core), so the compiled/platform-dependent surface sits behind mm_platform and mm_core stays INTERFACE-only. These two are one change (same boundary).
• W^X disabled in the board default. esp32/sdkconfig.defaults.esp32s3-n16r8 turns off CONFIG_ESP_SYSTEM_MEMPROT_FEATURE and enables CONFIG_HEAP_HAS_EXEC_HEAP for every build on that board, even with no MoonLive effect installed. The JIT genuinely needs a writable-then-executable heap, but that belongs in a dedicated MoonLive/JIT opt-in overlay or an explicit build profile, not the board default — so a stock build keeps memory protection on.
• A scenario rides timing + network. test/scenarios/light/scenario_modifier_chain.json carries tick_us baselines (host-performance dependent) and routes a modifier-chain-composition test through NetworkSendDriver (pulls network-path behavior into a test that is not about the network). It wants an in-process sink and structural assertions so it stays hermetic, per the test/** "no timing or network dependence" rule.

MoonI80 prime-only ring: no stall backstop (sibling-path gap)

Found: 👾 Reviewer, pre-commit on the whole-frame stall fix (2026-07-22).

The MoonI80 wait-timeout backstop (moonI80Ws2812Wait, platform_esp32_moon_i80.cpp) now recovers a lost/coalesced EOF on two of the driver's three completion paths: the lapping ring (nSlices > ringBufs, oracle-gated) and the whole-frame path (!isRing). The prime-only ring (isRing && nSlices <= ringBufs) falls through both conditions, so a lost terminator-EOF there leaves busy stuck true with no recovery — and every prime/arm/transmit-ring path refuses under busy, the same permanent-wedge class the whole-frame fix just closed.

Mitigated in practice: prime-only fires exactly one EOF per frame (no intra-frame coalescing), so the lost-EOF trigger is far rarer than on the whole-frame or lapping paths. But it is the same defect, and per the CLAUDE.md sibling-path rule (a cross-cutting recovery that core owns for one path should cover the sibling path, not be re-implemented per case) the backstop should extend to it rather than leave a third path uncovered.

Fix: widen the backstop's condition so a stuck prime-only ring finalizes too — likely a single "any ring frame whose wire time has elapsed with busy still set" oracle that subsumes both ring branches, calling the shared finalizeStalledTransfer. Verify on the expander wall (prime-only = the small-strand ring config), since the ring recovery is not desktop-testable.

Related (same file, same wall dependency): the whole-frame backstop stops the hardware before draining the FIFO and the EOF ISR drops a firing against an empty FIFO, which rejects a late EOF that arrives after recovery. A tighter guarantee — an ISR that has already passed the empty-FIFO guard cannot then clear a freshly-recovered busy or give wireFree for the next transfer — would need explicit serialization (disable the EOF interrupt across finalize+rearm, or an explicit recovery/rearm state the ISR checks). The window is extremely narrow (an ISR in-flight at the instant of finalize) and stopping GDMA+LCD first already disables the source; the hardened version is an ISR-concurrency change that must be proven on the wall, not landed blind.

ESP32-P4 400 MHz on rev-3+ silicon

Found: bench, 2026-07-25 (Quindor Discord question about the P4's 400 MHz).

The P4 build runs at 360 MHz because IDF's Kconfig.cpu caps a SELECTS_REV_LESS_V3 build (which we set, so a stock binary boots on the v0.x/v1.x P4 chips in the field) at 360; 400 MHz is IDF's default only for rev ≥ 3. Forcing 400 on our bench P4 (a rev v1.3 chip) was tried and bootloops — assert failed: esp_clk_init clk.c:105 — so 400 is a genuine hardware limit on pre-rev-3 silicon, not marginal stability. The ~11% compute headroom is left on the table for rev-3+ owners.

Two ways to reach it, both deferred until rev-3 P4 hardware is on the bench to validate: - A separate esp32p4-400 variant — sdkconfig with ESP32P4_REV_MIN = rev 3 + CONFIG_ESP_DEFAULT_CPU_FREQ_MHZ_400, so IDF's normal boot-time clock init sets 400 and the bootloader refuses to run on a pre-rev-3 chip (safe). The web installer offers it only to rev-3+ boards. This is the projectMM-idiomatic per-variant path. - A runtime bump — keep the 360 build (boots everywhere) and, at app_main, read esp_chip_info().revision and if ≥ 300 call rtc_clk_cpu_freq_mhz_to_config(400) + rtc_clk_cpu_freq_set_config. One binary, self-selecting. Riskier: a runtime CPU-PLL change on the P4 couples to the flash/PSRAM clock trees configured for 360, so it needs validation on real rev-3 hardware before shipping.

Neither ships until a rev-3 P4 can prove 400 runs clean — no untested clock config, per the same rule the S31/320 and this P4/400 bootloop both taught.

ESP32-P4: the esp-dsp assembly FFT faults once a second task runs (workaround shipped)

Found: bench, 2026-08-28, bringing up HLS on the P4.

Symptom: a crash loop the moment the HLS encode task exists alongside the render loop — Guru Meditation Error: ... (Illegal instruction) or (Load access fault), the type varying between boots, always faulting on the twiddle-table load in dsps_fft2r_fc32_arp4.S:52 (flw fa0, 0(t3)) reached from platform::audioFft. The LED output freezes after a few frames and the board reboots. Present only with audio analysis running AND a second task; either alone is stable, which is why it never surfaced before HLS.

Cause: the P4's hardware-loop unit has a documented silicon erratum, declared by Espressif's own soc_caps.h: SOC_CPU_HAS_HWLOOP_STATE_BUG — "HWLOOP state doesn't go to DIRTY after executing the last instruction of a loop". FreeRTOS saves the HWLP registers lazily and keys that save on the DIRTY flag, so a context switch out of the FFT concludes there is nothing to save and the loop state is lost; the resumed kernel then reads its table through a stale register. The esp-dsp _arp4 kernel uses esp.lp.setup (the hardware-loop instruction), which is why the FFT is where it lands. IDF v6.1-rc1 carries workarounds for this erratum at two sites in portasm.S (lines 217 and 795, gated ESP32P4_REV_MIN_FULL <= 1, which our REV_MIN_FULL=0 build satisfies) — both on the RESTORE side. The save site (~line 676) reads CSR_HWLP_STATE_REG, skips saving unless it equals HWLP_DIRTY_STATE, and carries no erratum guard at all. That is precisely what the erratum breaks: a task switched out after a loop's last instruction reports non-DIRTY, so its hardware-loop registers are never saved, and the resumed FFT reads its twiddle table through a stale register. Restore is patched; save is not.

Workaround shipped: CONFIG_DSP_ANSI=y in sdkconfig.defaults.esp32p4rev1-eth, which swaps esp-dsp's hand-written assembly kernels for portable C. Measured cost on the bench P4: the Audio module's tick goes from ~615 us to ~658 us, about 40 us (7%) against 3.3 ms of tick headroom. Stability confirmed over a soak with HLS streaming: zero crashes, zero corrupt packets.

Reported upstream: esp-idf#19025 (2026-08-28), which names the unguarded save path. Espressif already had the symptom on file from another reporter: esp-dsp#119 hits the same fault at the same instruction on IDF v5.5-beta1 and settles on the same CONFIG_DSP_ANSI=y workaround at the same ~7% cost, and esp-dsp#102 tracks P4 hardware loops in general. So the bug is real, reproducible by others, and spans at least v5.5-beta1 to v6.1-rc1 - but it is unfixed, and the workaround stays until it is answered.

What is NOT proven: the save-path gap is read from the source and matches every symptom, but it has not been confirmed by instrumenting the switch itself (logging CSR_HWLP_STATE_REG on a switch out of the FFT), nor reduced to a minimal project. Offered upstream if triage wants it. Ruled out on the bench, so nobody re-treads them: worker stack size (8K -> 16K), core placement (worker on core 1 vs core 0), heap corruption (comprehensive heap poisoning reports nothing), an unpinned task migrating with coprocessor state (our main task is pinned to core 0), an FFT size mismatch (512 <= 1024 <= 4096), and a cross-task race on the single audioFft call site. To report upstream (esp-dsp and/or esp-idf) with the repro above; the workaround stands until it is answered, and reverting it needs a bench soak with audio + HLS together.

Flaky unit tests: the AudioService sync suite contends on a fixed UDP port

Found: 2026-07-27, caught by premerge.py; pinned to the exact cases by looping the suite and keeping the failing logs. Fails roughly 1 run in 10.

Two cases in test/unit/core/unit_AudioService_sync.cpp fail intermittently, both around the socket rather than the audio logic:

• :125 "…drives frame_, then holds it and reports listening" — CHECK(strcmp(status(a), "listening") == 0). The receive path binds the fixed port kTestSyncPort (21988); when a previous run's socket is still in TIME_WAIT the bind fails and the service never reaches "listening".
• :95 "Local+send: lazy-opens once and reports sending" — CHECK(strcmp(status(a), "sending") == 0) plus syncOpenForTest(). This one connects to a broadcast address rather than binding, so it is a different failure mode on the same suite.

An attempted fix that did not hold (recorded so it is not retried blind). Deriving the port per run (from the steady clock) instead of the fixed constant cut the receive-path failures but left the send-path case failing ~3 in 20 — because that case never binds the test port, so the port was never its problem. The real fix has to address the send path's socket open on its own terms, not just port choice.

Why it matters: the gate scripts run the suite on every commit and merge, so a 1-in-10 flake interrupts gate lists often enough to train the reader to re-run instead of investigate — the habit that hides a real regression later.

Fix (do not paper over it): treat the two cases separately. For the receive path, bind an ephemeral port (bind 0, read the assigned port back) so two runs can never contend. For the send path, first determine why the lazy open fails under repetition — whether the broadcast connect is refused or the latch is left set by an earlier case in the same process. A retry wrapper or a sleep is explicitly the wrong fix: it hides the next genuine failure too. unit_NetworkReceiveEffect* and unit_SineEffect share the fixed-port shape and deserve the same treatment while the fix is fresh.

ModuleFactory: registration can fail silently (uint8_t ceiling, unchecked bool)

Found: 2026-07-27, while adding the effects grid sweep; flagged by the 👾 Reviewer.

ModuleFactory::registerType returns bool and appends unconditionally — it does not dedupe by name, so the same type registered from several places takes several slots (in the test binary Layer holds 9 and RainbowEffect 8). count_ is a uint8_t, and at the 255 ceiling grow() returns false, registration fails, and the return value is discarded at every call site — including the static-init registrars, which cannot check it anyway. The failure is silent: the type is simply absent from /api/types and create() answers nullptr for it, far from the cause.

Production is not near the ceiling today (~90 types), so this is not urgent. It became visible because a test binary that registers repeatedly can reach it, which is what made the grid sweep construct effects directly instead of registering them.

Options, cheapest first: (a) make registerType idempotent — ignore a duplicate name and return true, which fixes the multiplier and is arguably the correct semantic anyway; (b) widen count_/capacity_ to uint16_t (a handful of bytes, removes the ceiling as a practical concern); (c) make a failed registration loud in a debug build (assert or a boot-time log) so it can never be silent again. (a) plus (c) is probably the right pair.

Network-receive throughput starves HTTP (issue #69)

Found: 2026-08-20, reproducing issue #69 on MM-testbench-S3 (ESP32-S3, 240 MHz, v6.1-rc1).

Reported as "DDP gets very stuttery once the led count gets over a few thousand, even with no led drivers, and the same stream to WLED plays smoothly". Reproduced, and the threshold matches: HTTP availability while a DDP source runs, sampled 6 requests per point.

lights	pkt/s	KB/s	HTTP
480	30	44	6/6
1440	90	131	6/6
2880	180	262	6/6
4800	300	437	3/6
8160	510	743	0/6
12288	780	1136	0/6

Fully reversible: 8/8 before, 1/8 during, 8/8 after. Art-Net degrades the same way and, per light, sooner — it carries 170 lights/packet against DDP's 480.

The limit is throughput, not packet rate. Art-Net survived 510 pkt/s where DDP failed at 300, but both broke at ~440-480 KB/s. A matched-throughput control (~740 KB/s) gave 3/6 for DDP at 510 pkt/s and 2/6 for Art-Net at 1350 pkt/s — 2.6x the packet rate, same result. So a deeper LWIP_UDP_RECVMBOX_SIZE (6 today) is not the lever it looks like; the bytes have to be moved regardless of how they are grouped.

Not the render loop either. MM-S31 at 4096 lights held 6/6 all the way to 1966 KB/s while ticking at 12 fps (82 ms), against the S3's 8.3 ms tick. If the once-per-tick drain in NetworkReceiveEffect::tick() were the constraint, the board with the 10x slower tick would fail first. It is the fastest board that fails, which points at contention between the receive path and the HTTP task rather than at drain cadence.

Partly fixed 2026-08-20 (NetworkReceiveEffect, this branch). The staging→layer memcpy ran every tick whether or not a packet had arrived; the Layer does not clear the buffer between frames, so that copy was writing identical bytes. Guarding it on a dirty_ flag cut the effect's idle tick from 3522 us to ~240 us at 12288 lights (93%), measured on MM-testbench-S3. HTTP availability under load, same board, before → after:

lights	pkt/s	DDP before	DDP after
4800	300	3/6	6/6
8160	510	0/6	5/6
12288	780	0/6	2/6

Art-Net gains the same way (4800 lights 3/6 → 6/6; 1350 pkt/s 2/6 → 4/6) — the fix is on the shared staging path, not per protocol. The reported threshold ("a few thousand") is now clean; 12288 lights at 780 pkt/s still degrades.

Remaining work — measurement, not a fix: find where the rest of the bytes cost. Candidates are the recvfrom copy out of lwIP plus the staging→layer memcpy (both O(bytes/s), both on the render thread), and core-0 contention between the lwIP task and HTTP — the LC16 Ethernet starvation entry is the same shape. handleConnection running synchronously in tick20ms with ~5 ms/~50 ms budgets is the likely victim.

Related: WLED is smooth on the same stream because it receives via AsyncUDP — packets are consumed in a callback from the lwIP task the instant they arrive, rather than polled once per render tick. Moving to that model is the structural fix, and it needs staging_ synchronized against the render thread.

OSC pads and the Open Stage Control session's labels (2026-08-30)

Two gaps found wiring a real control surface to the OSC module.

/mm/pad/N has no handler. The OSC plan lists it (i 1 -> apply preset in slot 12), and OscModule::handle routes /mm/fader/, /mm/encoder/, /mm/switch/ and /mm/control/ but not pads. So a surface can drive every continuous control and every switch, but cannot fire a preset, which is the one thing a pad grid exists for. The route is small; what needs deciding is what a pad press means when the slot is empty, and whether a nonzero value is a press or a press-and-hold.

The shipped Open Stage Control session renders no labels, and its pad matrix draws nothing. docs/reference/examples/open-stage-control.json works for every fader, encoder and switch, but the widget names never appear and the matrix of pads is an empty box. Five attempts at the label property failed (@{}, JS{}, #{} with unit, an explicit string, omitting it so "auto" applies), and notably a session SAVED by Open Stage Control itself carries no label key on a fader at all, so the name is drawn from something else. The session was written by reading a minified app's bundled HTML docs; the reliable fix is to build one widget of each kind by hand in its editor, save, and copy the shape it produces. Cosmetic: the control path works, only the labels and the pad grid are missing.

POST /api/file reports success while writing an empty file (no Content-Length)

Found: 2026-08-20, on MM-testbench-S3, while uploading an edited MoonLive script. The upload answered {"ok":true} twice while the board kept the previous file, and a compile result was read from the stale script before the mismatch was noticed.

contentLen defaults to 0 when the request carries no Content-Length (HttpServerModule.cpp:152, "declared body length (0 if no Content-Length)"). handleWriteFile then clamps the already-buffered body against it:

const size_t initial = initialLen < contentLen ? initialLen : contentLen;   // → 0

so fsWriteStream streams nothing, succeeds, and the handler answers 200. The body on the socket is discarded. Reproduced deliberately: an 11-byte file written with Content-Length: 11 lands as 11 bytes; the identical request sent Transfer-Encoding: chunked answers {"ok":true} and leaves a 0-byte file, destroying what was there. Any HTTP client that streams without declaring a length hits this — curl --data-binary on a pipe, and chunked uploads generally.

This is data loss reported as success, which is the part that matters: a caller has no way to know the write did not happen, and the previous contents are already gone.

Options: (a) reject a body-bearing POST with no Content-Length (411 Length Required) — smallest, honest, and standard; (b) support Transfer-Encoding: chunked in the upload source, which is more work and only worth it if a real client needs it; (c) at minimum, never report 200 for a write whose byte count does not match what was declared. (a) plus (c) is the pair worth doing. The UI's own File Manager always sends a length, so this does not affect it — an API caller or a script does.

Pin with a test that a length-less upload does not report success and does not truncate the target.

repo-health compares numbers from different machines (2026-08-22)

repo-health.json records one value per metric with no note of which host produced it, so running the KPI gate on a second machine rewrites the baseline with figures that were never comparable. Measured on the same commit: desktop flash reads 1,060 KB on a Windows/MSVC bench against 1,165 KB recorded on macOS/clang, printed as "−105 KB ✓"; desktop tick reads 368 µs against 179 µs, printed as "+189 µs ⚠". Neither is a change in the code. The firmware rows are now guarded by a freshness rule, which stops a stale binary being re-measured, but freshness cannot detect a different compiler or a different CPU.

The file's own docstring states the property this breaks: "two machines agree and a number never moves for a reason nobody can explain". Two ways out, and it is a design call rather than a bug fix: key the host-dependent metrics by platform (flash.desktop.windows, perf.desktop.macos) so each machine tracks its own trend, or declare one canonical machine (CI) the only writer and have every other run print the delta without saving it. The second is less data and less honest about a Windows contributor's numbers; the first grows the file, which its "never grows" design resists. Until then, read a cross-host delta as noise.

MoonDeck scripts crash on Windows when run BY HAND (2026-08-22)

62 of the ~64 scripts print → ✓ ⚠ — or box-drawing characters. Run from a Windows terminal their stdout takes locale.getpreferredencoding() — cp1252 — and the first such character raises UnicodeEncodeError, after the real work has succeeded: collect_kpi.py measures everything, writes the metrics, then dies printing the summary arrow. Every path is now exposed: the gate runner that handed children PYTHONIOENCODING=utf-8 is gone, so a Windows agent run hits it too, not only the human path MoonDeck exists for.

Per-script sys.stdout.reconfigure() is the wrong shape at 62 files: every new script would have to remember, and the one that forgets fails in the field. It wants ONE home — the candidates are a PYTHONUTF8=1 in whatever env MoonDeck's front ends already establish, or a shared moondeck/_stdio.py imported by the handful of scripts that are entry points. Pick when someone next runs a check by hand and it dies on a tick mark.

disasm.py cannot run on Windows (2026-08-21)

The tool shells out to c++ and objdump to build the per-ISA emitter and disassemble its bytes, and a Windows machine carrying only MSVC has neither. That holds for every ISA, not just the new x86_64 one — but x86-64 is where it bites, because the host it disassembles is now a Windows desktop and the tool is what turns "the script did nothing" into an answer. The x86-64 backend was brought up without it, using byte-pinning tests plus WinDbg on the emitted image; that worked, and was slower than reading the instructions would have been.

Closing it is a compiler/disassembler pair behind the two subprocess.run calls: cl.exe for the build, and for the disassembly either LLVM's llvm-objdump (which understands -b binary the way the tool already expects, and ships with the VS "C++ Clang tools" component) or a .obj wrapper around dumpbin /disasm, which does not. Prefer the former — the flags are already right, so it is a lookup rather than a second code path.

A non-ASCII Windows profile path defeats the desktop settings directory (2026-08-23)

std::getenv("LOCALAPPDATA") returns the ANSI form of the path, so a Windows user whose profile name carries characters outside the system codepage (CJK and Cyrillic on a Western machine; most accented Latin survives cp1252) gets ? where those characters were. ? is not legal in a Windows filename, so create_directories fails, fsMount returns false, and the driver reports cannot use ..., persistence disabled naming the mangled path. It degrades visibly rather than corrupting anything, which is the standard Principle 5 asks for, but that user has no working persistence.

Reading the variable wide is only half of it. toFsPath composes a std::filesystem::path, which stores wide on Windows, but every open in the layer goes back through .string() to reach std::fopen (fsRead, fsReadAt, fsWriteAtomic, fsWriteStream, and the mount probe), a narrowing the code comments on deliberately at fsRead. So a wide LOCALAPPDATA alone would produce a correct path that still cannot be opened: the fix is one _wfopen-on-Windows helper shared by all five sites, plus a test with a non-ASCII root.

Not done with the per-user data directory because it reverses a documented decision across the whole desktop filesystem layer, four of whose five call sites predate that change. What the change did do is make the root capable of containing a username, where it was previously the literal build. Worth closing the next time this file is opened for other reasons.

Opt-in usage reporting: know which hardware and configurations are actually out there (2026-09-01)

We build for hardware we cannot see. Which chips people actually run, how big their walls are, which drivers and features they enable, and how many are still on an old version are all questions currently answered by whoever happens to speak up on Discord. That is a biased sample: it hears from people with problems and from people who post, and it is silent about the majority who install something and it simply works. Effort therefore goes where the loudest reports are rather than where the users are, and a decision to drop support for something rests on a guess.

What a report would carry. Enough to answer "what should we build and what may we stop supporting", and nothing else:

• The machine. Chip family and variant for a device (classic ESP32, S3, P4, S31 and so on), flash size, whether PSRAM is present and how much. For a desktop, the OS and architecture instead, which is a question we have no way to answer at all today.
• The version. Firmware or application version, release channel, and on an upgrade the version it came from. Whether this was a fresh install or an upgrade.
• The light setup, in shape rather than content. Total light count, which layouts are in use and their dimensions, which drivers are active, and how many outputs or buses. Not what the wall shows, only how big it is and how it is wired.
• Which features are switched on. The modules present and enabled: audio, MoonLive, MQTT, Art-Net or E1.31 send and receive, panel cards, Ethernet versus WiFi. This is the half that answers "is anyone actually using this", which is what decides whether a feature earns its maintenance.
• A country, derived at the server from the address the request arrives from, so the map is by region rather than by installation.

What it must never carry, and this list is a constraint on the design rather than a note on it: device name, IP or MAC address, WiFi credentials, MQTT passwords, any free-text field a user typed, the contents of a layout or a script, and anything that lets two reports be recognized as the same installation. There is no device identifier, which also means no de-duplication: a machine reporting twice counts twice, and that inaccuracy is the price of not being able to track anyone. It is the right trade.

Consent. Opt-in, from a prompt shown after a fresh install or an upgrade, with a decline that is as easy to click as the accept and is remembered. One report per install or upgrade, never a heartbeat. A user who declines transmits nothing at all, rather than transmitting a "declined" record.

The privacy policy already commits to this shape (docs/privacy-policy.md), including the honest wording about the IP address a server unavoidably sees. Whatever is built has to match what is promised there, and the policy has to be updated with the specifics BEFORE the feature ships, not alongside it.

Open questions for whoever picks this up. Where the server runs and who administers it, since it is the first piece of infrastructure this project would own rather than borrow from GitHub. Whether the dashboard is public, which we would want it to be for the same reason the source is. Whether the desktop reports at all or only devices, given the desktop is the half we currently know nothing about. And what happens to a report from a version whose fields have since changed, because a schema that cannot be read a year later answers nothing.

A driven GPIO the Pins map never sees: bus padding, and a hidden clockPin

Found: 2026-08-21, on MM-S31, after a bench session that started as "the LED panel stopped working" and cost hours chasing a firmware regression that did not exist.

An ESP32-S31 driving a ColorLight receiver card over raw Ethernet showed the panel dark while every diagnostic said the transmit path was healthy: link negotiated at 1000 Mbit, ~4600 packets/s, zero drops, and a byte-for-byte dump of a 128x128 frame matched ColorLight5A75Packet.h exactly. The card's own activity LED never blinked. Four firmware versions across two ESP-IDF releases behaved identically.

The cause is a GPIO collision that no part of the system could report. ParallelLed carried clockPin = 10, and GPIO 10 is txd2 on the S31's RGMII bus (platform_esp32.cpp: the EMAC's fixed IO_MUX pads are 8-19 plus MDC/MDIO on 5/6). The LED driver drove one of the four Ethernet transmit data lines, so every frame left the MAC counted-as-sent and arrived corrupt. Disabling the LED drivers fixed it instantly; moving the clock to GPIO 21 fixed it with all four drivers running.

Three separate defects made this invisible, and each is worth fixing on its own:

1. Pins the map cannot see, because nothing declares them. The shipped conflict soft-flag grades what modules declare, so an undeclared pin is invisible to it however hard the silicon drives the pad. Three cases, two now closed:

• ✅ Bus-padded lanes (fixed): a one-strand board had seven i80 lanes parked on clockPin, driven at bus-clock rate and listed nowhere. spareLanesNeedPad() stops the padding on a backend that routes its own GPIOs, so the pin is no longer driven and the map is truthful again.
• ✅ RGMII data pads (fixed): all twelve are now published by NetworkModule as read-only pin controls from one platform::ethRgmiiPads list that ethInitEmac also reads. Verified on MM-S31: gpio 10 reports as ethTxd2.
• ✅ P4 RMII data pins (fixed): the six lines the EMAC drives are in platform::ethFixedPads and reported through fixedPins(), same as the S31's RGMII pads. Verified on MM-P4: Network owns all ten of its Ethernet GPIOs (28/29/30/34/35/49 plus MDC 31, MDIO 52, clock 50, reset 51), against four before.
• ✅ Classic ESP32 RMII data pins (fixed): TX_EN 21, TXD0 19, TXD1 22, CRS_DV 27, RXD0 25, RXD1 26, entered as a third ethFixedPads branch. Sourced from IDF's own RMII Data Plane GPIO table (docs/en/api-reference/network/esp_eth.rst): one IO_MUX choice per signal, which is why ethInitEmac never sets them. Verified on MM-Olimex: all ten Ethernet pins claimed, Eth: 192.168.1.210 (100 Mbit).
• ✅ MDC/MDIO on the classic ESP32 (fixed): the chip default was mdc -1, mdio -1, so ethInitEmac skipped the assignment, IDF applied its own 23/18, and the map claimed neither. ethConfigDefault now states 23/18, sourced from IDF's own classic default and our QuinLED Dig-Octa entry. Verified on MM-Olimex: Eth: 192.168.1.210 (100 Mbit) with gpio 23 MDC and gpio 18 MDIO in the map. NOTE: a board with -1 already persisted keeps it until those controls are set once or NVS is erased.

The fix is the RGMII one, extended. Being fixed in silicon does not make gpioCapability's reserved list the right home: reserved means "routing I/O here corrupts the device" (flash, PSRAM, USB), which is unconditional, while an EMAC pad is only held while that interface runs. With ethType = None the init returns false and every one of those GPIOs is free for LEDs, so a static reserved list would permanently forbid pins a WiFi-only board can use. What makes a control the right shape is not that the pin is configurable (it is not) but that the claim is CONDITIONAL: published when the interface is selected, released when it is not, which is exactly what the pin map reads.

So the same platform::ethRgmiiPads treatment applies, with one wrinkle. On the classic ESP32 the RMII data pins are silicon-fixed, so a second per-chip pad list serves them directly. On the P4 49/34/35/28/29/30 is the Waveshare NANO's board wiring that the IDF macro happens to default to, not a chip constant, so those belong in deviceModels.json beside the other per-board eth pins, letting a different P4 carrier declare its own. Both then reach the pin map through the control path already built, rather than a third mechanism.

Lower risk than the RGMII case (six pins rather than twelve, and nothing of ours currently collides), but the failure mode is identical: a driver claims one, the MAC still reports a healthy link, and every frame goes out corrupt.

2. busPinList() pads spare lanes with clockPin, and MoonI80 routes them as data. The i80 bus is always 8 or 16 bits wide (ParallelLedDriver::busWidthPins), so a board driving one strand gets seven lanes parked on the clock pin, and configureGpio (platform_esp32_moon_i80.cpp) routes every entry it is given. The padding exists because esp_lcd rejects an NC data pin, but the MoonI80 backend does not have that limit: its own comment says "pins past laneCount go nowhere". It is simply never told the real lane count. Passing it would free six or seven GPIOs on every direct-mode board and remove the hidden claim at the source.

3. clockPin defaults to 10 and is hidden. MoonLedDriver::clockPin = 10 is a hardcoded default that lands inside the S31's reserved RGMII block, and addBusControls hides the control unless pinExpanderMode() is on. So on this board the value was invisible on the card, unchangeable through the UI, and still driving a pad. A pin with a real effect must be visible, whatever mode it is in.

This also closed the S31 Ethernet defect, open since 2026-07-26. That entry (removed) blamed an RGMII Tx-clock mismatch at 100M for DHCP never completing, and had concluded "the frames never reach the router". The cause was the same collision: ParallelLed's default clockPin = 10 is txd2, so a DHCP DISCOVER was garbled exactly as the panel frames were. With the clock pin moved off the RGMII block the S31 leases normally, verified on the bench at Eth: 192.168.1.125 (1000 Mbit). Two long-standing bugs, one GPIO.

Input transports: foot pedals, USB game controllers, and MoonLive at the pins (2026-09-01)

ButtonService shipped with the GPIO seam (gpioInputBegin / gpioRead / gpioWrite). It names a target as Module.control and writes it through Scheduler::setControl, so a press and an OSC message are indistinguishable downstream. Three follow-ups build on that seam rather than beside it.

Foot pedals are two different things, corrected in input-mapping-analysis.md: a footswitch is a switch on a TS jack, which ButtonService in momentary mode already covers, while an expression pedal is a potentiometer on a TRS jack, which is an ADC read mapping onto a fader and does not exist yet. Neither is USB. Action: document the footswitch, scope the expression pedal as an analog-input service.

USB game controllers are their own project, and are S3/P4-only. The mapping half is trivial once reports arrive (buttons to pads, axes to encoders and faders, all through setControl); the transport half is not:

• The classic ESP32 cannot do it at all: no USB Host peripheral, no USB OTG. So the Dig-2-Go, and every classic board, is out from the start.
• S3 and P4 have USB-OTG and the IDF ships a USB Host stack with a HID class driver. A gamepad is a HID device whose report descriptor must be parsed to learn which byte is which button or axis, and that parsing is the real work: descriptors vary per vendor, and the well-known controllers each have quirks.
• Desktop would go through the OS gamepad API behind the same seam, a wholly separate implementation.

Expect a plan of its own, after the GPIO inputs have settled. The honest scope is "a HID report parser plus a mapping UI", not "read a controller".

MoonLive at the pins is the piece that makes the seam pay twice. The direction is that MoonLive gains driver scripts whose hello-world is "read from GPIO, write to GPIO", which needs:

• gpioRead(pin) / gpioWrite(pin, on) as builtins, mapping straight onto the platform seam.
• setControl(module, control, value) as a builtin. This one needs a decision before it ships: it is the same primitive every transport already uses, so exposing it is consistent, but it also lets any script write any control on any module. That is power worth granting deliberately rather than as a side effect.
• A MoonLiveService host module, the service twin of MoonLiveEffect: a script control, the compile and status path, the picker integration. Mostly a copy of the existing binding, and it is what turns "MoonLive can read a pin" into "a user can add a scripted service".

ButtonService is then the precompiled sibling of a script anyone could write, exactly the relationship ballpit.mle has with BallpitEffect.

Relay-gated boards, and what a driver is (2026-09-01)

Wiring a QuinLED Dig-2-Go found that its LED supply sits behind a relay on GPIO 12, the vendor's "LED Relay enable pin". Undriven, the data line is perfectly correct and the strip stays dark, which is a hard failure to diagnose from the firmware side. Drivers now carries a relayPins list that follows the master on control.

A list, because boards do not agree. The Dig-2-Go has one relay for one LED output; the Dig-Next-2 has four relays for two outputs, all carrying the same Relay_LightsOn role in MoonLight's own model. So a relay maps to neither the device nor a driver, and every one of them follows master power together. It lives beside on rather than on a driver because a relay gates the SUPPLY, which several drivers share, where a driver's own controls describe that one driver's output.

Still open: the definition of a driver. Two statements in the repo disagree. drivers.md:3 says "A driver sends lights somewhere", while architecture.md:143 frames drivers as the consumer half of producers vs consumers. The product owner's definition is broader than both and is the one to adopt: a driver communicates with hardware or the network, which explicitly includes talking to GPIOs.

The concrete tension is in code: DriverBase declares virtual void setSourceBuffer(Buffer*) = 0, so every light driver is structurally required to consume the light buffer, and all sixteen do. The resolution is that there are two families of one idea, split by whether the light buffer is involved: a light Driver (Drivers container, consumes the buffer, outputs it) and a core Service (Services container, a capability bridge, no buffer). services.md already says exactly this. Action: scope drivers.md's claim to light drivers, and name the general sense in architecture.md. Documentation only, no code.

The device catalog cannot seed a list row (2026-09-01)

deviceModels.json describes a board by the modules it adds and the controls it sets, and the config push turns that into three ops: planConfigOps (mooninstaller/config-ops.js) emits add, set and clearChildren, and HttpServerModule's APPLY_OP handler accepts exactly those. There is no op for creating a row in a list control, on either side.

Found rebuilding the infrared service around a mapping list. Its five old actions (on/off, brightness up/down, palette next/prev) were meant to ship as default rows so a remote still worked out of the box, and they cannot: a row is not a control, so controls: {...} cannot express one. The service therefore starts empty and a user adds their first row by hand.

Seeding them in the module's own setup() was tried and reverted: it works, but it puts a board's opinion in firmware, which is exactly what the rebuild removed, and it collides awkwardly with restoreList (which runs first on a configured device, so the guard is "only seed an empty list" and the interaction is subtle enough to have cost a debugging round).

What it would take: an addListRow op carrying the parent module, the list control's name, and the row's fields, then a setListRowField per field (or one op with the whole row). The device side already has both primitives on ListSource, so this is plumbing rather than design: the catalog schema, the planner, the APPLY_OP encoding and the handler. Worth doing when a board genuinely ships with pre-bound inputs (a panel with three labelled buttons), which is also when someone can say what the rows should be.

Until then a list is user-populated, which is the honest behavior: the device knows the pin, the user knows what the button should do.
