ParticlesEffect

Source: ParticlesEffect.h

ParticlesEffect

class ParticlesEffect

src/light/effects/ParticlesEffect.h:22

Inherits: EffectBase

Particle-system effect with spawned, moving points.

Author: WildCats08 / @Brandon502 (MoonLight), https://github.com/ewowi/MoonLight/blob/main/src/MoonLight/Nodes/Effects/E_MoonLight.h

Points drift, bounce off the walls and leave a fading trail behind them. The physics belong to particles::Pool, and what stays here is the drift rate and the hue map.

Public Attributes

uint8_t count = 32 : How many particles are alive.

uint8_t speed = 80 : How fast they drift.

uint8_t fade = 240 : How much of the trail each reference frame keeps.

uint8_t hue_shift = 0 : Walks every particle's color around the palette.

Public Methods

virtual inline const char * tags() const override : Catalog tags: MoonLight origin, David Jupijn and Rising Step.

virtual inline Dim dimensions() const override : Iterates y and x, so the trail covers the z=0 plane and extrude fills a volume.

virtual inline void defineControls() override : Publish the population, the drift, the trail and the palette shift.

virtual inline void prepare() override : Size the trail and the pool, and seed every particle once.

virtual inline void tick() override : Fade the trail, move the particles, draw them into it, then copy it to the layer.

Public Static Attributes

constexpr uint8_t MAX_PARTICLES = 64 : The pool's size, of which count are alive at a time.

More info

Both carries exist for the same reason

The fade and the motion each spend a fraction of a reference frame per tick. At a high frame rate that fraction truncates to zero, so the remainder accumulates instead. Without it a fade of 240 never decays and the trail turns solid, and a slow speed never moves.
